Je bekijkt pagina 32 van 36
32
Specication - DVI Dual View Secure KVM
IOGEAR DVI Dual View Secure KVM (CAC and Non-CAC models)
Function GCS1222TAA4C GCS1224TAA4C GCS1228TAA4C GCS1222TAA4 GCS1224TAA4 GCS1228TAA4
Computer
Connections
Direct 2 4 8 2 4 8
Maximum 2 4 8 2 4 8
Console Connections 1 Direct 1 Direct
Port Selection Pushbutton, Remote Port Selector Pushbutton, Remote Port Selector
Connectors Console
Ports
Keyboard 1 x USB Type A Female 1 x USB Type A Female
Video 2 x DVI-I DL Female 2 x DVI-I DL Female
Mouse 1 x USB Type A Female 1 x USB Type A Female
Speaker 1 x Mini Stereo Jack Female (Green) 1 x Mini Stereo Jack Female (Green)
Microphone N/A N/A
CAC 1 x USB Type A Female N/A
KVM Ports Keyboard/
Mouse
2 x USB-B
Female
4 x USB-B
Female
8 x USB-B
Female
2 x USB-B
Female
4 x USB-B
Female
8 x USB-B
Female
Video 4 x DVI-I DL
Female
8 x DVI-I DL
Female
16 x DVI-I DL
Female
4 x DVI-I DL
Female
8 x DVI-I DL
Female
16 x DVI-I DL
Female
CAC 2 x USB-B
Female
4 x USB-B
Female
8 x USB-B
Female
N/A
Speaker 2 x Mini Stereo
Jack Female
4 x Mini Stereo
Jack Female
8 x Mini Stereo
Jack Female
2 x Mini Stereo
Jack Female
4 x Mini Stereo
Jack Female
8 x Mini Stereo
Jack Female
Microphone N/A N/A
Power 1 x 3-Prong AC Socket 1 x 3-Prong AC Socket
Remote Port Selector 1 x RJ-11 1 x RJ-11
Switches Port 2 x Pushbuttons 4 x Pushbuttons 8 x Pushbuttons 2 x Pushbuttons 4 x Pushbuttons 8 x Pushbuttons
Reset 1 x Semi-recessed Pushbutton 1 x Semi-recessed Pushbutton
Power 1 x Rocker 1 x Rocker
LEDs On Line / Selected 2 (Orange) 4 (Orange) 8 (Orange) 2 (Orange) 4 (Orange) 8 (Orange)
CAC activated 2 (Green) 4 (Green) 8 (Green) N/A N/A N/A
Power 1 (Green) 1 (Green)
Key Lock LED 3 (Green; Num Lock, Caps Lock, Scroll Lock) 3 (Green; Num Lock, Caps Lock, Scroll Lock)
Console Video 2 (Green, on rear panel) 2 (Green, on rear panel)
Emulation Keyboard/Mouse USB USB
Video DVI Dual Link: 2560 x 1600* DVI Dual Link: 2560 x 1600*
I/P Rating 100-240V~; 50-60Hz; 1A (TBD) 100-240V~; 50-60Hz; 1A (TBD)
Environment
Physical
Properties
Operation Temperature 32 - 122F (0-50°C) 32 - 122F (0-50°C)
Storage Temperature 4 - 140F (-20 – 60°C) 4 - 140F (-20 – 60°C)
Humidity 0-80% RH, Non-condensing 0-80% RH, Non-condensing
Physical
Properties
Housing Metal Metal
Weight 4.72lb (2.14kg)
(TBD)
4.81lb (2.18kg)
(TBD)
7.36lb (3.34kg)
(TBD)
4.72lb (2.14kg)
(TBD)
4.81lb (2.18kg)
(TBD)
7.36lb (3.34kg)
(TBD)
Dimension 13.19” x 6.42”
x 2.58” (33.5cm
x 16.3cm x
6.5cm)
13.19” x 6.42”
x 2.58” (33.5cm
x 16.3cm x
6.5cm)
17” x 9.27” x
2.58” (43.24cm
x 20.4cm x
6.55cm)
13.19” x 6.42”
x 2.58” (33.5cm
x 16.3cm x
6.5cm)
13.19” x 6.42”
x 2.58” (33.5cm
x 16.3cm x
6.5cm)
17” x 9.27” x
2.58” (43.24cm
x 20.4cm x
6.55cm)
*IOGEAR Single / Dual View Dual-Link DVI Secure KVM Switches oer 3840 x 2160 @ 30Hz video output on compatible HDMI-interfaced
monitors and / or computers and used with IOGEAR DVI-to-HDMI KVM cables
