English • 19
troubleshooting
6
What to do in case of a malfunction? In most cases, you will be able to correct these faults easily yourself. Please check the
solutions below before contacting the Inventum service department.
The motor is not running
• Is it plugged in correctly?
• Is there a power outage?
• Check the electrical installation.
The performance of the cooker hood is not correct and makes more nois.
• Is the diameter of the exhaust-air pipe correct?
• Is the duct blocked?
• The diameter of the duct must be 150 mm. A smaller diameter can negatively influence the suction of the motor.
• Are the grease filters clean?
• Is the carbon filter not replaced within the last 6 months? Replace the carbon filter.
• Is there enough air supply to replace the extracted air?
Read these installation instructions carefully before starting the installation.
Decide whether there is a duct available or if the cooker hood needs to recirculate. We advise to install the cooker hood
with two persons.
• The minimum distance between the supporting surface for the cooking pans on the cooker and the lowest part of the
hood must be:
- 55 cm for an electric, ceramic or induction cooker
- 65 cm for a gas hob
• If the cooker hood is to be fitted to an existing duct no other aplliances, such as a geyser or heater, may be connected to
that same duct.
• The shorter the duct, and the fewer the bends in it, the better the cooker hood will work.
• The connection pipe for the cooker hood has a diameter of 150 mm.
installation
7
150
ELEKTRISCH
550
GAS 650
X
Y
A
1
2x 80
2x
8x36mm
2x
4x30mm
2
3
4x
4x30mm
4x 80
4x
8x36mm
2x
upper support = 274 mm
Optional:
lower support = 263,5 mm
