S AVE THESE INSTRUCTIONS

(347IO) SPA ENGLISH 7.5” X 10.3” PANTONE 295U 05/19/2023

English

Page 8

When ordering parts, be sure to quote the model number and part numbers.

PARTS (continued)

Before assembling your product, please take a few minutes to check the contents

and become familiar with all the parts.

REF.

NO.

DESCRIPTION QTY.

PART NO.

4 ADULTS 6 ADULTS

28426 28430 28476 28428 28432

1 CONTROL BASE 1 12836 12836B 12836 12836 12836B

2 SIDE COVER HINGE BASE 2 12771D 12771D 12771D 12771D 12771D

3 SIDE COVER HINGE FIXER 2 12772D 12772D 12772D 12772D 12772D

4 CONTROL BASE SIDE COVER 2 12770W 12770B 12770W 12770W 12770B

5 CONTROL PANEL 1 12840 12840B 12840 12840 12840B

6 PANEL FIXER 1 10064 10064B 10064 10064 10064B

7 SPA/COVER INFLATION HOSE 1 11830 11830 11830 11830 11830

8 SPA CONTROL INLET/OUTLET O-RING 2 11699 11699 11699 11699 11699

9 SPA CONTROL AIR INLET O-RING 1 11687 11687 11687 11687 11687

10 SPA DRAIN PLUG 1 13076 13076 13076 13076 13076

11 SPA DRAIN VALVE ADAPTOR 1 13036 13036 13036 13036 13036

12 FILTER CARTRIDGE HOUSING 1 11798 11798 11798 11798 11798

13 FILTER CARTRIDGE 2 11692 11692 11692 11692 11692

14 FILTER CARTRIDGE HOUSING LID 1 11797 11797 11797 11797 11797

15 INLET/OUTLET PLUG 3 11739 11739 11739 11739 11739

16 SPA TUB 1 11842 12260 11842 12106 12258

17 SPA COVER 1 11841 12261 12752 12107 12256

SPA COVER INFLATABLE BLADDER

(PRE-INSTALLED IN SPA COVER)

1 11689 11689 12753 12108 12108

19 GROUND CLOTH 1 11717 11717 11717 12109 12109

20 CHEMICAL DISPENSER 1

12735 12735 12735 12735 12735

21 TEST STRIPS 1 11855 11855 11855 11855 11855

22 WRENCH 1 11742A 11742A 11742A 11742A 11742A

23 AIR PRESSURE RELEASE VALVE CORE 1 12589A 12589A 12589A 12589A 12589A

24 HOSE ADAPTOR (PRE-INSTALLED WITH #7) 1 12773 12773 12773 12773 12773

25 MALE BUCKLE

6 11698 11698B - 11698 11698B

1 - - 11698 - -

26 FEMALE BUCKLE

6 11799 11799B - 11799 11799B

1 - - 11799 - -

27 DEFLATION OUTLET CAP 1 12775W 12775B 12775W 12775W 12775B

28 DEFLATION HOSE ADAPTOR 1 12774 12774 12774 12774 12774

29 SPA FILTER MOTOR 1 12778 12778 12778 12778 12778
