345A
SAVE THESE INSTRUCTIONS
(345IO) SAND FILTER PUMP COMBO ENGLISH 7.5” X 10.3” PANTONE 295U 07/10/2020
English
Page 5
REF. NO. DESCRIPTION QTy.
SPARE PART NO.
ECO20220-2/ECO20230-2 ECO15220-2/ECO15230-2
1 PRESSURE GAUGE 1 11224 11411
2 6-WAY VALVE 1 11496 11378
3 DRAIN OUTLET COVER 1 11131 11131
4 CLAMP 1 11380 11380
5 TANK O-RING 1 11379 11379
6 SAND SHIELD 1 11382 11382
7 CENTER PIPE HUB 1 11814 11813
8 LATERAL 12 11384 11384
9 DRAIN VALVE CAP 1 11456 11456
10 DRAIN VALVE O-RING 1 11385 11385
11 L-SHAPE O-RING 7 11228 11228
12 HOSE WITH NUTS 2 11010 11010
13 SAND FILTER INTERCONNECTING HOSE 2 11535 11388
14 LEAF TRAP NUT 1 11479 11822
15 LEAF TRAP O-RING 1 11232 11824
16 BASKET 1 11260 11821
17 FILTER HOUSING NUT 1 11261 11261
18 TEST STRIPS 1 19635 19635
19 AIR RELEASE VALVE/SEDIMENT RELEASE VALVE 2 10460 10460
20 VALVE O-RING 2 10264 10264
21*
PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED)
2 10747 10747
22* HOSE O-RING 2 10262 10262
23* STEP WASHER 2 10745 10745
24* STRAINER NUT 2 10256 10256
25* FLAT STRAINER RUBBER WASHER 2 10255 10255
26* THREADED STRAINER CONNECTOR 1 10744 10744
27* ADJUSTABLE POOL INLET JET NOZZLE 1 12369 12369
28* ADAPTOR B 2 10722 10722
29* STRAINER CONNECTOR 1 11070 11070
30* POOL INLET JET NOZZLE 1 12364 12364
31* STRAINER GRID 1 12197 12197
32 SCREW 2 11381 11381
33 PUMP MOTOR & CONTROL 1 13040 13038
34 PRE-FILTER ASSEMBLY 1 11371 11826
35 LEAF TRAP COVER 1 11480 11823
36 SAND FILTER PUMP MOTOR INLET O-RING 2 11457 11457
37 SAND FILTER PUMP TANK 1 12714 12713
38 SAND FILTER PUMP TANK BASE 1 12870 12869
39 PRE-FILTER HOUSING 1 12099 12100
40* STRAINER GRID 1 12198 12198
41* AIR JET VALVE 1 12363 12363
42* INLET THREADED AIR CONNECTOR 1 12372 12371
43* POOL INLET AIR ADAPTOR 1 12368 12368
44* INLET STRAINER CONNECTOR 1 12365 12365
45* AIR JET VALVE CAP (NOT SHOWN) 1 12373 12373
46 CELL HOUSING 1
12864 12864
47 TITANIUM PLATES O-RING 1
12871 12871
48 TITANIUM ELECTRODE 1
13043 13042
49 E.C.O. ELECTRODE 1
12875 12874
50 E.C.O. ELECTRODE O-RING 1
12876 12876
51 ELECTROLYTIC CELL NUT 1
13044 13044
" * ": These parts are not included if this pump was not purchased as part of a pool set. Contact our
Authorized Service Centers to order these parts if needed.
When ordering parts, be sure to quote the model number and part numbers.
