Intergas Heating Ltd 15
3 Ventilation
When the appliance is started the fan is first brought to starting speed.
When the starting speed has been reached the burner is lit. Code 3 is also
visible when post-ventilation is taking place after the burner has stopped.
4 Ignition
When the fan has reached the starting speed, the burner is ignited by
means of electrical sparks. During ignition the code 4 is visible. If the
burner does not ignite, a new ignition attempt occurs after approximately 15
seconds. If after 4 ignition attempts the burner is not yet burning, the burner
manager goes into fault mode. (See section 10).
5 CH operation
An of/off thermostat, an OpenTherm thermostat, an external sensor or a
combination of the latter can be connected to the burner manager. (See
section 11.5)
When a request for heat is received from a thermostat, the fan is started (code
3 ), followed by ignition(code 4 ) and CH operating mode(code 5
During CH operation the fan speed and hence the appliance power are
controlled by the burner manager so that the CH water temperature reaches
the desired CH supply temperature.
If an on/off thermostat is connected, this is the CH supply temperature set
on the display. In the case of an OpenTherm thermostat the desired CH
supply temperature is determined by the thermostat.
In the case of an external sensor the desired CH supply temperature is
determined by the heating line programmed in the burner manager. For the
latter two, however, the maximum is the temperature set on the display.
The CH operation the requested CH supply temperature is indicated on the
operating panel.
The CH supply temperature set to 75°C and can be adjusted between 30°C
and 80°C. If, under circumstances a flow temperature is needed up to 90°C
the value of parameter 5. (max. value for flow temperature in display) needs
to be adjusted. (See section 9.1).
The actual CH supply temperature can be read by pressing the service
button during CH operation.
When the DHW comfort function is switched on (See code 7 ) any
OpenTherm request for heat of less than 40°C is ignored.
6 DHW operation
The hot water supply takes priority over the heating. If the flow switch
detects a need for more than 2 l/min of DHW, any demand for CH will be
interrupted. After the fan has reached speed (code 3 ) and ignition has
taken place (code 4 ) the manager goes to DHW mode (code 6 ).
During DHW operation the fan speed, and hence the power of the
appliance, are controlled by the burner manager so that the DHW water
temperature reaches the DHW temperature setting.
The water temperature can be set between 40°C and 65°C (See section
9.1) and is displayed on the operating panel during DHW operation.
The actual DHW temperature can be read by pressing the service button
during DHW operation.
