Intergas Heating Ltd 60
11. MAINTENANCE
The appliance and the installation should be checked and if necessary cleaned
every year by a registered expert.
For assembly and disassembly the following tools can be used:
1. Cross head screwdriver
2. Allen key 6 mm
3. Fork spanner 30 mm
After servicing you must complete the Benchmark Service Record section located
on page 60 of this document.
CAUTION
Work on gas carrying parts may only be carried out by an authorised
installer.
When the appliance has just been operating parts may be hot.
Domestic use only. Service intervals may need to be increased
depending on commercial usage. This includes seals being replaced
more frequently. For additional information please contact Intergas
Heating Ltd.
CAUTION
The integrated insolation and burner seal contain ceramic
fibres.
11.1 Disassembly
1. Switch off the appliance using the On/Off key on the operating panel.
2. Switch off the electrical supply to the appliance.
3. Close the gas tap.
4. Unscrew the two sunken screws left and right at the front underneath the
appliance and lift/remove the front panel.
5. Wait until the appliance and the burner have cooled down.
6. Remove the connectors from the gas valve and the fan.
7. Disconnect the coupling beneath the gas valve.
8. Unscrew the 10 shoulder bolts from the front cover and remove this forwards
complete with gas valve and fan.
While removing the front cover do not hold this at the gas valve and/or the fan.
Be careful not to damage the burner and the fan while removing the front plate.
9. The burner does not need any maintenance.
10. Never clean the burner with a brush or compressed air. This causes damage to
the metal fibre.
11. Clean the bottom side of the heat exchanger and the condensate discharge at
the bottom of the flue discharge behind the heat exchanger.
12. The condensate must be thoroughly cleaned from the heat exchanger
13. Remove the cup of the internal siphon at the bottom side of the boiler.
CAUTION
The amount of condensate water in the internal siphon
exceeds the content of the cup. Please make sure a bucket is
held under the cup when removing it.
14. Clean the siphon cup and the condensate discharge pipe.
15. After cleaning, fill the siphon with water by removing the hose that comes from
the PRV. After filling the siphon make sure the hose is placed back
Note
A regular inspection of the build in expansion vessel pressure is advisable. Access
to re-pressurise the expansion vessel is at the rear back of the vessel.
