Intergas Heating Ltd 32
7.6 Flue system
7.6.1 General
• The boiler is prepared to be connected to a concentric flue system 60/100.
• The flue system must be connected to the flue adapter of the boiler.
The internal seals ensure the air tightness of the connection.
• By replacing the standard adapter for a flue adapter 80mm and removing the
plastic cap from the air inlet in the top of the boiler, the boiler can be made
suitable for connecting to a 80/80 twin flue system
Explanation flue system category
Category
Explanation
C13
The terminal is located in the façade; the inlet for the air
supply duct is located in the same pressure area as the
terminal.
Example: combined wall terminal
C33
The terminal is located above the roof; the inlet for the air
supply duct is located in the same pressure area as the
terminal of the flue piping.
C53
Closed unit, connected to separate air supply duct and flue
pipes, terminated in various pressure zones.
Draft, materials and insulation
Flue type
Diameter
Material
Concentric
60/100
Aluminium, Stainless steel of PP (T120)
Air inlet
ø 80 mm
According to (local) regulations of the fire
department and/or energy supply company.
Approved material incl. seals
- Aluminium
- Plate steel (galvanised)
- Stainless steel
- Plastic.
N.B. Rain water drainage pipes are not allowed
Flue gas
ø 80 mm
- Aluminium in accordance to EN 1856-1 of
EN 1856-2
- Plastic in accordance to EN 14471
N.B. Temperature class T120
Insulation
-
10 mm vapour-tight insolation material.
Applicable when risk on condensation on the
outside is present.
7.6.2 Sealed flue system .
Concentric connection.
A. Mount the concentric flue pipe in the flue adapter of the boiler. The integrated
seal will secure an air- tight connection.
