Intergas Heating Ltd 14
4.7 Integrated clock
The boiler incorporates an integrated clock, which allows the setting of central
heating periods (See the User Instructions, ‘Operation and display read-out’ for
details) and the boiler’s control panel incorporates an LED display, which indicates
the state of operation and fault defect codes.
4.8 Operation
The Intergas Rapid is a wall-mounted modulating high efficiency boiler. This
means that the power is adjusted to the heat demand.
In the aluminium heat exchanger two separate copper circuits have been
integrated.
Because of the separated circuits for central heating and hot water, the heating
and the hot water supply can operate independently of each other. The hot water
supply has priority over the heating. They cannot work simultaneously.
The appliance has been provided with an electronic burner controller that controls
the fan with the heat demand from the heating system or the hot water supply,
opens the gas valve and ignites the burner and continuously monitors the flame
and controls it dependent on the power required.
4.9 Operating modes
A code on the service display of the operating panel indicates the
appliance’s operating mode.
- Off
The appliance is out of operation but is supplied with electrical power. No
response occurs to calls for DHW or CH. The appliance frost protection is
active. This means that the pump operates and the exchanger is heated up
if the temperature of the water present in it falls too far.
If the frost protection is actuated, code 7 is displayed (heating exchanger).
In this operating mode the pressure in the CH installation (in Bar) can also
be read on the temperature display.
Waiting mode
The LED at the button is lit and possibly one of the LEDs for the DHW
comfort function. The appliance is ready to respond to a request for CH of
DHW.
0 Running on of CH
After the end of CH operation the pump continues to run. The running on
time is factory set at he value in accordance with section 9.3 , page:46. This
setting can be changed.
In addition, the pump runs automatically for 10 seconds once every 24
hours in order to prevent seizing. This automatic switching on of the pump
occurs at het time of the last call for heat.
1 Desired temperature reached
The burner manager can temporarily block the request for heat. The burner
is then stopped. Blocking occurs because the requested temperature has
been reached. When the temperature has fallen sufficiently the blocking is
cancelled.
2 Self-test
he connected sensors are checked regularly by the burner manager. During
the check the manager does not perform any other tasks.
