Assembly Instructions | Montageanleitung l 3
PARTS LIST
DIN 912 M10X25 INBUS SCREW 8 8 8 8 8 8 8 8
DIN 912 M6X12 INBUS SCREW 22 26 14 18 22 26 14 18
DIN 125 M6 FLAT WASHER 22 26 14 18 22 26 14 18
M5 X12 TORX BOLT (External 6-lobe) 4 4 28 28 4 4 28 28
M12X85 ADJUSTABLE FEET 4 4 4 4 4 4 4 4
M12*20 PLASTIC BOLT 4 4 4 4 4 4 4 4
BOTTOM FRAME ASSEMBLY 1 1 1 1 1 1 1 1
TOP FRAME ASSEMBLY 1 1 1 1 1 1 1 1
VERTICAL PROFILE 4 4 4 4 4 4 4 4
SIDE SUPPORT RAILS 2 2 2 2 2 2 2 2
SIDE SUPPORT ADAPTER 0 0 4 4 0 0 4 4
19" MOUNTING RAILS 4 4 4 4 4 4 4 4
SIDE PANEL 2 0 2 0 2 0 2 0
SPLIT SIDE PANEL 0 4 0 4 0 4 0 4
SPLIT SIDE PANEL MIDDLE PART
0 2 0 2 0 2 0 2
TOP COVER
1 1 1 1 1 1 1 1
REAR METAL SOLID PANEL
1 1 1 1 0 0 0 0
FRONT DOOR
1 1 1 1 0 0 0 0
FRONT & REAR PERFORATED DOOR
0 0 0 0 2 2 2 2
LOCK BRACKET 0 0 0 0 1 1 1 1
W=600, D=600 - 800
W=600, D=1000-1070-1200
W=800, D=600 - 800
W=800, D=1000- 1070-1200
W=600, D=600 - 800
W=600, D=1000-1070-1200
W=800, D=600-800
W=800, D=1000-1070-1200
Note: Use the above parts list to check that all parts are accounted for before you start assembling. If any
parts are missing, please contact your reseller or distributor for replacements.
