Regulatory Information

regs.htm[8/8/2016 2:38:04 PM]

determine the required host regulatory testing and/or obtaining the required host approvals for compliance.

Intel® wireless adapters are intended for OEMs and host integrators only.

The Intel® wireless adapter FCC Grant of Authorization describes any limited conditions of modular approval.

The Intel® wireless adapters must be operated with an access point that has been approved for the country of

operation.

Changes or modification to Intel® wireless adapters by OEMs, integrators or other third parties is not

permitted. Any changes or modification to Intel® wireless adapters by OEMs, integrators or other third parties

will void authorization to operate the adapter.

Antenna Type and Gains

Only antennas of the same type and with equal or less gains as shown below may be used with the Intel® wireless

adapters. Other types of antennas and/or higher gain antennas may require additional authorization for operation.

Antenna

Type

Antenna

Location

(Main/Aux)

2.4GHz Peak

Gain in dBi*

2.6GHz Peak

Gain in dBi*

5.2GHz Peak

Gain in dBi*

5.5GHz Peak

Gain in dBi*

5.7GHz Peak

Gain in dBi*

PIFA Main

Aux 3.24 3.47 3.73 4.77 4.77

MIMO

*All antenna gains include cable loss.

Antenna Placement Within the Host Platform

To ensure RF exposure compliance the antenna(s) used with the Intel® wireless adapters must be installed in

notebook or tablet PC host platforms to provide a minimum separation distance from all persons, in all operating

modes and orientations of the host platform, with strict adherence to the table below. The antenna separation

distance applies to both horizontal and vertical orientation of the antenna when installed in the host system.

Wireless Adapter Minimum required antenna-to-user separation distance

Intel® Centrino® Wireless-N 100 9 mm

Intel® Centrino® Wireless-N 105 9 mm

Intel® Centrino® Wireless-N 130 8 mm

Intel® Centrino® Wireless-N 135 9 mm

Intel® Centrino® Wireless-N 1000* 20 mm

Intel® Centrino® Wireless-N 1030 8 mm

Intel® Centrino® Wireless-N 2200 9 mm

Intel® Centrino® Wireless-N 2230 6 mm

Intel® Centrino® Advanced-N 6200* 20 mm

Intel® Centrino® Advanced-N 6205 12 mm

Intel® Centrino® Advanced-N 6230 12 mm

Intel® Centrino® Advanced-N 6235 8 mm

Intel® Centrino® Ultimate-N 6300 13 mm

Intel® Dual Band Wireless-AC 7260 8 mm

Intel® Dual Band Wireless-N 7260 8 mm

Intel® Wireless-N 7260 8 mm

Intel® Dual Band Wireless-AC 3160 8 mm

Intel® Dual Band Wireless-AC 3165 8 mm
