Specifications

specs.htm[8/8/2016 2:38:06 PM]

Intel® Dual Band Wireless-AC 7260

Form Factors Half-Mini Card and M.2 (Next Generation Form Factor - NGFF)

Electrical interfaces PCIe and USB 2.0 for both form factors

Antenna Interface

Connector

Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066

Antenna Diversity On-board diversity

IEEE 802.11

Networking Standards

Intel® Dual Band Wireless-AC 7260

Model 7260HMW - 802.11agn, ac, 2x2, Bluetooth 4.0, PCIe, USB, HMC

Model 7260NGW - 802.11agn, ac, 2x2, Bluetooth 4.0, PCIe, USB, M.2

Operating

Temperature

0 to +80 degrees Celsius

Humidity 50% to 95% non-condensing (at temperatures of 25 ºC to 35 ºC)

Frequency

Modulation

5GHz (802.11ac/n) 2.4GHz (802.11b/g/n)

Frequency band 5.15GHz - 5.85GHz (dependent on country) 2.400 - 2.4835GHz (dependent on country)

Modulation BPSK, QPSK, 16 QAM, 64 QAM, 256 QAM CCK, DQPSK, DBPSK

Wireless Medium 5GHz UNII: Orthogonal Frequency Division

Multiplexing (OFDM)

2.4GHz ISM: Orthogonal Frequency Division

Multiplexing (OFDM)

Channels All channels as defined by the relevant specification and country rules.

Spatial streams Intel® Dual Band Wireless-AC 7260: 2 X 2

Data Rates All data rates are theoretical maximums.

IEEE 802.11ac Data

Rates

Intel® Dual Band Wireless-AC 7260: Up to 867 Mbps

IEEE 802.11n Data

Rates

Tx/Rx (Mbps): 300, 270, 243, 240, 216.7, 195, 180, 173.3, 150, 144, 135, 130, 120, 117,

115.5, 90, 86.667, 72.2, 65, 60, 57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2

IEEE 802.11a Data

Rates

54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11g Data

Rates

54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11b Data

Rates

11, 5.5, 2, 1 Mbps

Bluetooth Dual Mode Bluetooth* 2.1, 2.1+EDR, 3.0, 3.0+HS, 4.0 (BLE) supported by the following

adapters

Model 7260HMW

Model 7260NGW

General

Operating Systems Windows* 7 (32-bit and 64-bit), Windows* 8 (32-bit and 64-bit), Windows* 8.1 (64-bit)

Wi-Fi Alliance*

certification

Wi-Fi CERTIFIED* for 802.11ac, a/b/g, n, WMM*, WPA*, WPA2*, and WPS, WPS 2.0,

Protected Management Frames. Wi-Fi Direct* for peer-to-peer device connections.

Architecture Infrastructure and SoftAP; Supports simultaneous Client and SoftAP modes

Cisco Compatible

Extensions certification

Cisco Compatible Extensions, v4.0

Security

Authentication WPA and WPA2, 802.1X (EAP-TLS, TTLS, PEAP, LEAP, EAP-FAST), EAP-SIM, EAP-AKA
