Specifications

specs.htm[8/8/2016 2:38:06 PM]

Connector

Interface

52-pin Mini Card edge connector

Voltage 3.3 V

Operating

Temperature

0 to +80 degrees Celsius

Humidity 50% to 95% non-condensing (at temperatures of 25 ºC to 35 ºC)

Frequency

Modulation

5 GHz (802.11a/n) 2.4 GHz (802.11b/g/n)

Frequency band 5.15 GHz - 5.85 GHz (dependent on country) 2.400 - 2.4835 GHz (dependent on country)

Modulation BPSK, QPSK, 16 QAM, 64 QAM CCK, DQPSK, DBPSK

Wireless

Medium

5 GHz UNII: Orthogonal Frequency Division

Multiplexing (OFDM)

2.4 GHz ISM: Orthogonal Frequency Division

Multiplexing (OFDM)

Channels All channels as defined by the relevant specification and country rules.

IEEE 802.11n

Data Rates

Tx/Rx (Mbps): 300, 270, 243, 240, 216.7, 195, 180, 173.3, 150, 144, 135, 130, 120, 117, 115.5,

90, 86.667, 72.2, 65, 60, 57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2

IEEE 802.11a

Data Rates

54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11g

Data Rates

54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11b

Data Rates

11, 5.5, 2, 1 Mbps

Bluetooth Bluetooth Version 4.0 (3.0 +HS )

General

Operating

Systems

Windows* 7 (32-bit and 64-bit), Windows* 8 (32-bit and 64-bit), Windows* 8.1 (32-bit and 64-

bit)

Wi-Fi Alliance*

certification

Wi-Fi* certification for 802.11b, 802.11g, 802.11a, 802.11h, 802.11d, WPA-Personal, WPA-

Enterprise, WPA2-Personal, WPA2-Enterprise, WPS, WMM, WMM Power Save, EAP-SIM, LEAP,

PEAP, TKIP, EAP-FAST, EAP-TLS, EAP-TTLS, EAP-AKA, P2P

Cisco

Compatible

Extensions

certification

Cisco Compatible Extensions, v4.0

WLAN Standard IEEE 802.11g, 802.11b, 802.11a, 802.11n

Architecture Infrastructure or ad hoc (peer-to-peer) operating modes

Security WPA-Personal, WPA2-Personal, WPA-Enterprise, WPA2-Enterprise, AES-CCMP 128-bit, WEP 128-

bit and 64-bit; 802.1X: EAP-SIM, LEAP, PEAP, TKIP, EAP-FAST, EAP-TLS, EAP-TTLS, EAP-AKA

Product Safety UL, C-UL, CB (IEC/EN 60950-1)

Intel® Centrino® Advanced-N + WiMAX 6250 and Intel® Centrino®

Wireless-N + WiMAX 6150

Form Factor PCI Express* Half-Mini Card

Dimensions Half-Mini Card: Width 1.049 in x Length 1.18 in x Height 0.18 in (26.64 mm x 30 mm x 4.5 mm)

Antenna

Interface

Connector

Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066

Antenna

Diversity

On-board diversity

Connector 52-pin Mini Card edge connector
