4.3. Status LEDs
Status LED Blue LED Red LED
Constantly on
Connected to WiFi N/A
Slow Flashing
Connecting via WPS Camera at work
Fast Flashing
No connection to WiFi Upgrading rmware
O
LED is turned o, or camera is
not plugged into power
LED is turned o, or camera is
not plugged into power
1 - Infrared LEDs 5 high-powered IR LEDs (nightvision @ 850nm) and 2 switch-
able status LEDs (blue and red, see description below)
2 - Lense Wide-angle (focal length: 4.3mm / eld of view: ~ 100º dia.)
3 - Photosensor Twilight switch for IR LEDs
4 - PIR Detector Integrated Panasonic passive infrared (PIR) motion detector
5 - Microphone For noise detection / audio rec. / two-way audio intercom
6 - Audio Output 3.5mm jack for earphone / active speaker
7 - Network Port RJ45 LAN port / connector for Cat5e LAN cable or higher
8 - Power Connector For included 12V / 2A power supply
9 - MicroSD Card Slot Slot for MicroSD/SDXC cards (max. 1024GB / 1TB
- 32GB included in the camera -
10 - WPS / Reset 3 seconds for WPS WiFi setup / 20 seconds for reset
11 - Status LED Red: power; blue: network status (Please refer to Section 4.3)
12 - Antenna
Connector
RP-SMA WiFi antenna connector for 2 antennas
13 - 2x Antennas 3.5 dB Antennas (option: add INSTAR antenna extension
cable)
14 - IP66
Connector
For sealing cables with IP66 protection. Dierent scenarios
available for 1-cable, 2-cables, 3-cables
15 - Rubber-Joint 1-cable, 2-cable, 3-cable rubber-joint for dierent connection
purposes. (Please refer to Section 4.4 for more details)
16 - IP66 Nut To close the IP66 connector and to seal the rubber ring
17 - Bracket For wall mounting and overhead installation
