16-EN
Image Sensor
Sensor 1/3” WQHD Sony IMX335 STARVIS CMOS Sensor
Lens f = 2,7mm - 13.5mm; F/1.6 (Wide) - F/2.95 (Tele)
Angle of View 30° - 120° diagonal eld of view
Video Properties
Video Encoding h.265 / h.264 high, main and baseline / MJPEG
Video Framerate Up to 30fps
Supported Resolutions 2560x1440, 1920x1080 und 1280x720 Pixel
Flip / Mirror Image Horizontal / vertical
Video Settings Brightness / contrast / saturation / exposure...
Communication
Network Interface 10Base-T/100Base-TX ethernet port
Wireless 5GHz / 2.4GHz, Wi-Fi 5 (802.11ac)
WiFi Frequency Range 2.4 - 2.4845Ghz, 5,150 - 5,350 / 5,470 - 5,725Ghz
WiFi Transmission Power <16dBm @ 11b/g, <15dBm @ 11n <18dBm@ 11ac
WPA / WPA2 Encryption TKIP / AES (CCMP)
PoE (Power over Ethernet) IEEE 802.3at (+ Pin 4 and 5 / - Pin 7 and 8)
Hardware
PIR Detector Passive Infrared Motion Detector
Infrared LEDs 6 High-Power IR LEDs / 20-30m eective range
White lights 6 High-Power Illumination Light Source-LEDs
MicroSD Card Reader For MicroSD / SDXC cards up to 256 GB (32 GB included)
Power Supply Output: 12V DC 2A / Input: 100-240V
Power Consumption Max. 16 Watt (in normal operation 3,6 Watt)
Operating Temperature - 20°C to 55°C
Requirements
Web Browser Web browser supporting HTML5
CPU / Graphic Card Dual core (min. 2Ghz) / 256MB+ graphic card
Bandwidth Min. 512kbs per camera
12. Technical Data
