www.inline-info.com

QUICK REFERENCE SHEET

COMMAND HOTKEYS

FRONT-PANEL BUTTON DESCRIPTION

Select PC Port²

(Jointly select PC port/ hub port control/ audio&mic,

if binding is enabled)

ScrLk + ScrLk + X

X=1-2 / 1-4 (PC port number)

Press the corresponding button to select the active PC port.

Select the active PC port (jointly select PC port/

hub port control/ audio&mic, if binding is ena-

bled)

Select Hub Port Control

(Jointly select PC and hub port control, if binding is

enabled)

ScrLk + ScrLk + Fx

Fx=F1-F2/F1-F4, x=Hub port number

Press the button to toggle the speciﬁc PC+USB hub port

control. (It works only if PC port/ hub port control binding

is enabled.)

Select the PC port that control all USB hub ports

(jointly select PC & hub port control, if PC/ hub

port control binding is enabled)

Select Audio&Mic Port

(Jointly select PC port and audio&mic, if binding is

enabled)

ScrLk + ScrLk + Fy

Fy=F5-F6/F5-F8, y=audio/mic.-port number

Select the active audio&mic port (jointly select

PC & audio&mic port, if binding is enabled)

Bind PC and Hub Port Control Switching

[Default] ScrLk + ScrLk + Z

Enable the binding of PC port and hub port con-

trol (once this feature is enabled, any PC and/

or hub port control switching is bound together)

(factory default)

Unbind PC and Hub Port Control Switching

[Default]

ScrLk + ScrLk + X

Disable the binding of PC port and hub port con-

trol

Bind PC and Audio&Mic Switching

[Default] ScrLk + ScrLk + Q

Enable the binding of PC port and audio&mic

switching. (once this feature is enabled, any PC

and/or audio&mic switching is bound together)

(factory default)

Unbind PC and Audio&Mic Switching

[Default] ScrLk + ScrLk + W Disable the binding of PC port and audio&mic

Previous PC port

(Jointly select PC/ hub port control, if binding is

enabled)

ScrLk + ScrLk +

↑ (Arrow Up)

Select the previous connected PC port (jointly

select PC/ hub port control, if binding is

Next PC port

(Jointly select PC/ hub port control, if binding

enabled)

ScrLk + ScrLk +

↓ (Arrow Down)

Select the next connected PC port (jointly select

PC/ hub port control, if binding is

Previous PC port

ScrLk + ScrLk + ← (Back Space)

Toggle between the previous port and current

Beep Sound On/Off ScrLk + ScrLk + B Toggle on/off the beep sound

Deﬁne Hotkey Preceding

ScrLk + ScrLk + H + y

y=Scroll Lock, Caps Lock, ESC, F12, Num Lock

Press and hold down last button ( Button 2 / Button 4 ) till two

beeps, release the button, then press (y)

Select the hotkey preceding sequence among 5

alternative keys

Auto Scan ScrLk + ScrLk + S

Autoscan through every connected port for

quick screen browsing of each port (scan delay

= 5 sec.)

Autoscan with Programmable Delay

ScrLk + ScrLk + H + z

z=1>10s, 2>20s, 3>30s, 4>40S, 5>50s, 6>60s, 7>70s, 8>80s,

9>90s, 0>100s

Auto scan with a user-deﬁned delay time within a

range of 10 ~ 100 seconds

Stop Auto Scan Press any button Terminate Autoscan activity

Notes: 1. The USB keyboard hotkeys allows you a faster and broader control for your KVM switching operation in addition to the front-panel button. If you have conﬁgured a hotkey preceding sequence other than two consecutive scroll locks, here you should change your hotkey se-

quence accordingly. (For preceding sequence key conﬁguration, please refer to “Deﬁne Hotkey Preceding Sequence” in above table.)

2. When the binding of PC & USB hub port control switching is enabled by the hotkey sequence: ScrLk + ScrLk + Z, any PC and hub port control switching are bound together. To remove this binding, use the

hotkey sequence: ScrLk + ScrLk + X.

3. When the binding of PC and audio&mic switching is enabled by the hotkey sequence: ScrLk + ScrLk + Q, any PC and audio&mic switching are bound together. To remove this binding, use

the hotkey sequence: ScrLk + ScrLk + W.

Dual Monitors HDMI/DP USB KVM Switch w/ Audio & Mic -- Operation Commands for Hotkeys / Front-Panel Button
