Page 10

4) Connect one end of the AC power cord to the AC In jack on the back of the speakers.

5) Connect the other end of the AC power cord to the AC Out jack on the bottom connector panel of the display.

ON/OFF

POWER

SUB L

INPUT

6) Plug the speakers’s audio cable into the Audio Out (RCA R/L) jack on the bottom connector panel located on the

back of the display.

7) Turn the power switch ON.

Attaching the HD video conferencing camera

1) Remove the plastic ﬁlm from the camera lens.

2) Align the camera bracket with the screw holes on the top edge of the backside of the display and then secure the

camera to the display with the two provided thumb screws.

3) Plug the USB cable into the USB slot immediately below the camera on the back of the display.

4) Manually tilt and pan the camera (+/- 40°) as desired.
