Page 14
OSD (ON-SCREEN DISPLAY) MENU SYSTEM
The OSD provides the user the ability to control the display.
To access the OSD, press the Menu button on the remote or the keypad located on the right-hand side of the display.
Use the up and down arrows on the remote or keypad to scroll through the menu options and press OK to enter the highlighted menu.
Use the up and down arrows and OK button to select the item you would like to adjust. Left and right arrow buttons are used to make
adjustments.
When your adjustments are complete, press the Back button to go to a dierent menu or press the Menu button to exit the OSD menu
entirely.
The following pages describe each of the OSD menus in detail.
Sel Adjust Enter Back Quit
< >
<
<
BRIGHTNESS
CONTRAST
SHARPNESS
COLOR TEMPERATURE
COLOR CONTROL
PICTURE MODE
PICTURE RESET
NATIVE
STANDARD
NO
70
50
50
100
100
100
RED
GREEN
BLUE
Sel Adjust Enter Back Quit
< >
<
<
SCREEN
H POSITION
V POSITION
CLOCK
CLOCK PHASE
BLANK
DIMMING
ASPECT RATIO
SCREEN RESET
50
50
50
50
OFF
70
WIDE
NO
Sel Adjust Enter Back Quit
< >
<
<
PIP
PIP MODE
PIP INPUT
PIP POSITION
PIP SWAP
PIP SIZE
PIP AUDIO
PIP RESET
NO
VGA
TOP-RIGHT
NO
SMALL
MAIN
NO
Sel Adjust Enter Back Quit
< >
<
<
CONFIGURATION 1
LANGUAGE
AUTO SOURCE
USB HUB SWITCH
CONFIGURATION RESET
FACTORY RESET
ENGLISH
NO
AUTO
NO
NO
Sel Adjust Enter Back Quit
< >
<
<
CONFIGURATION 2
OSD TURN OFF
FREEZE
OSD H POSITION
OSD V POSITION
OSD ROTATION
MONITOR INFORMATION
10
50
50
OFF
PORTRAIT
