ISSUE POSSIBLE CAUSES TROUBLESHOOTING STEPS
The RICOHYBRID will not turn on.
The IBP-1H battery pack is very low or has
completely discharged.
Charge the battery pack.
The RICOHYBRID can not connect to a
computer or external power supply.
External power supply has completely
discharged.
Check the external power supply and charge it if necessary.
Computer is turned o. Power on the computer.
Data cable is damaged. Replace the data cable.
The RICOHYBRID can not connect to the
mobile device (smartphone or tablet).
Wi-Fi is not turned on. Turn on the Wi-Fi in the main menu. See Main Menu > Wi-Fi on page34.
Wrong Wi-Fi password entered.
On the mobile device, go to Settings > Wi-Fi and enter the correct password. The default
password is 12345678. See
Main Menu > Wi-Fi on page34.
Too many Wi-Fi signals near the RICOHYBRID. Move the RICOHYBRID and mobile device to an area with no or fewer Wi-Fi signals.
Wi-Fi signal is lost or interrupted.
Smartphone or tablet is out of range of a strong
Wi-Fi signal, or there are obstacles between
the RICOHYBRID and the mobile device.
• Try again when the Wi-Fi signal is stable.
• Relocate the RICOHYBRID closer to the Wi-Fi signal.
The image is fuzzy, not clear,
not balanced, or has artifacts.
Non-uniformity correction is required.
Perform a non-uniformity correction. See Non-uniformity Correction on page23 and
See Using the Quick Menu on page19.
The image is too dark. Display brightness level is too low. Adjust the display brightness in the quick menu. See Using the Quick Menu on page19.
The GUI is clear, but the image is fuzzy.
The lens is not focused.
• Adjust the focus on the target by rotating the objective focus knob (2).
• Adjust the image sharpness in the quick menu. See Using the Quick Menu on page19.
There is dust on the interior or exterior optical
surfaces of the lens.
• Wipe the external optical surface with the included microfiber lens cloth.
There is condensation on the interior or
exterior optical surfaces of the lens.
• Wipe the external optical surface with the included microfiber lens cloth.
• Allow the RICOHYBRID to dry by leaving it in a warm, dry environment for at least 4 hours.
The aiming reticle shifts after
firing rounds.
The RICOHYBRID is not mounted securely or
the mount is not secured on the RICOHYBRID.
• Check that the RICOHYBRID has been securely mounted.
• Make sure you are using the same brand, type, and weight of the bullets as when the
RICOHYBRID and weapon were initially zeroed.
• If the RICOHYBRID was zeroed in dierent environmental conditions, a slight shift of the zero
is possible.
The image of the object being observed
is missing.
Looking through glass. Remove any glass windows from the field of view.
The RICOHYBRID will not focus.
Image settings are not optimal for the current
environmental conditions or the object being
observed.
• Check the external surface of the objective lens and eyepiece and, where necessary, wipe
away any dust, condensation, frost, etc.
• In cold weather, you can use special anti-fogging coatings, such as those made for corrective
glasses.
• Adjust the focus on the target by rotating the objective focus knob (2).
• Adjust the image sharpness in the quick menu. See Using the Quick Menu on page19.
• Adjust the image and device settings. See Quick Start Guide on page8.
Image quality is too low or the detection
range is reduced.
These issues may occur due to the weather
conditions, such as snow, rain, humidity,
and fog.
Short press the Palette Button to set the imaging mode to fog mode.
When the RICOHYBRID is used in
low-temperature conditions, the image
quality of the surroundings is worse than in
warm-temperature conditions.
Environmental conditions.
In warm-temperature conditions, objects being observed (surroundings and background) heat
up dierently because of thermal conductivity, thereby generating a high-temperature contrast.
Accordingly, image quality produced by the rifle scope will be higher. In low-temperature
conditions, the background will cool down to roughly the same temperature, and thus the
temperature contrast is substantially reduced and image detail can go down as there is less
contrast in the scene. This is a normal function of a thermal imager and is no indicator of actual
detector performance.
