1. OVERVIEW
The InfiRay Outdoor RICO HYBRID HYH75W fuses the capabilities of
a thermal clip-on and a thermal weapon sight to create a new breed of
thermal device. The HYH75W has a 75mm lens and sports a flat dark-
earth Cerakote finish. It provides versatility and performance,as well
as compatibility with day optics up to 10× as an inline clip-on sight. The
combination of the HYBRID’s low-distortion eyepiece and a 1.03-inch
large-format 2560×1920 AMOLED display provides comfortable
viewing as a dedicated sight while still maintaining the pixel density
and resolution required for use as a thermal clip-on. The HYH75W
also boasts advanced features such as compatibility with a 1,000-yard
laser rangefinder, a custom reticle generator, and an onboard ballistic
solver. The HYH75W comes with all the features night hunters love
such as mobile streaming over Wi-Fi and audio/video recording.
2. FEATURES
• 12 μm high-performance thermal detector
• ≤25 mK sensitivity
• High image quality
• Magnesium housing
• Quick-change rechargeable battery pack
• Maximum detection range 3600 yards
• HD 2560×1920 AMOLED display with low-distortion eyepiece
• High frame frequency: 50Hz
• Compatible with ILR-1000-2 Laser Rangefinder Module
(optional/not included)
• Advanced recoil-mitigating mount for improved accuracy
• Multiple reticle types and color options
• Onboard ballistic solver and BDC reticle
• Recoil activated video
• Standalone and clip-on optic modes
• Multiple zero profiles and ranges
• Digital Zoom: ×1/×2/×4/×8
• Built-in 64 GB storage to support image capture and
video recording
• Built-in Wi-Fi module
• Mobile device App compatible
• ROI (Region of Interest) mode
• Built-in digital compass and gravity sensor
• Picture in Picture (PIP)
• User-friendly interface
• Pixel calibration functions
3. TECH SPECS
RICOHYBRID HYH75W
SENSOR
Resolution 640×512
Pixel Size 12 μm
Frame Rate 50hz
Sensor Sensitivity ≤25 mK
Image Processing MATRIX III
Core InfiRay Micro II 640
OPTICS
Objective Lens 75 mm f/1.0
Magnification 4×
Digital Zoom 8×
Field of View 5.9° × 4.4°
Detection Range 3600 Yards
Display Type 1.03-inch Large-format AMOLED
Display Resolution 2560×1920
Color Palettes White Hot, Black Hot, Red Hot, Iron Red, Rainbow, Outline
Reticle Types 9 (7 Static, 1 DIY, 1 BDC)
Reticle Colors Black, White, Red, Green, Blue
Mounting System Picatinny MIL-STD 1913 Rail
P.I.P. Yes
Rangefinder ILR-1000-2 LRF (Optional/Not Included)
Eye Relief 60 mm
Diopter Range -4 to +2
ELECTRONICS
Onboard Recording Video, Recoil-Activated Video, and Image
Onboard Storage 64 GB
Wireless Connectivity Image and Video via App.
Data/Power Connector USB-C
Power Supply USB-C External, IBP-1H Li-ion Battery Pack (6+ Hours)
Start Up Time <10 Seconds, Instant from Standby
PHYSICAL
Size 12.20” × 4.13” × 3.58”
Weight 45.08 Oz
ENVIRONMENTAL/WARRANTY
Warranty 5 Years
Housing Material Magnesium
Ingress Protection IP67
Operation Temperature -4°F~122°F
Max. Recoil 1000 g/s² (300 Win./7mm Mag)
