7. QUICK START GUIDE
Step 1: Preparing to Use the BOLT TL35V2
1. Compare the box contents to the accessories list and examine
each for any shipping damage. See Accessories on page4.
2. Check the lens to ensure there are no smudges or dirt present.
Clean with the included lens cloth, if necessary.
3. Charge the built-in battery pack before using the BOLT TL35V2
for the first time. See Charging the Built-in Battery Pack on
page10.
4. Install the eyeguard(1).
5. Mount the BOLT TL35V2 to the weapon using the included
30mm rings. See Mounting the BOLT TL35V2 on page15.
Step 2: Turn On and Adjust the Focus
1. Open the objective lens cap (15).
2. Long press the Power
button for 3 seconds to power on the
TL35V2. The InfiRay Outdoor logo will appear.
3. Rotate the diopter adjustment ring (2) of the eyepiece until the
interface icons are clearly visible.
4. Rotate the objective lens focus ring (14) to focus on the object
being observed.
WARNING: Do not point the objective lens toward intense
energy sources, such as the sun. This may render the electronic
components inoperative. The warranty does not cover damage
caused by improper operation.
Step 3: Activate and Customize the Reticle
The reticle may be inactive when the TL35V2 is powered on for the
first time. To activate the reticle, press and hold the Brightness
and Photo
Buttons at the same time for at least 15seconds.
From the home screen:
1. Short press the Control Turret to enter the quick menu (see
Using the Quick Menu on page8):
a. Select the reticle type, from 1–6.
b. Set the reticle color to white, black, red, or green.
Step 4: Adjust Image Settings
From the home screen:
1. Short press the Palette
Button to set the color palette to
white hot, black hot, red hot, color, or highlight.
2. Short press the Brightness
Button to adjust the screen
brightness, from 1–5. The screen brightness icon
and
selected brightness level appear at the bottom of the screen.
3. Short press the Control Turret to enter the quick menu to adjust
the image sharpness, from 1–5. See Using the Quick Menu on
page8.
4. Rotate the Control Turret to zoom in and out on the observed
object. See Digital Zoom on page26.
5. Long press the Palette
Button to turn on the PIP window. See
Picture in Picture (PIP) on page26.
6. Short press the Power
Button to perform a manual
non-uniformity correction, as needed. See Non-Uniformity
Correction (NUC) on page22.
7. Long press the Control Turret to enter the main menu to turn on
Ultra-Clear mode to enhance the image contrast in inclement
weather. See Ultra-Clear Mode on page27.
Step 5: Adjust Rifle Scope Settings
1. From the home screen, long press the Control Turret to enter
the main menu to:
a. Change the non-uniformity correction (NUC) mode to
automatic, manual, or background. See Main Menu >
Calibration on page30.
b. Turn on the digital compass. See Main Menu > Compass on
page30.
c. Turn on the motion sensor. See Main Menu > Motion Sensor
on page31.
d. Set the zeroing profile to A, B, or C. See Main Menu > Rifle
Selection on page32.
e. Calibrate the digital compass. See Main Menu > Compass
Calibration on page38.
f. Set the date and time. See Settings Menu > Date and
Settings Menu > Time on page39.
g. Set the units of measurement to meters or yards. See
Settings Menu > Units of Measure on page40.
Step 6: Zero the TL35V2
1. Zero the rifle scope following the instructions in Zeroing the
BOLT TL35V2 on page21.
a. Select, or customize, a preset zero distance that matches
the target distance. See Reset Zeroing Distance Menu >
Zero Distance Submenu on page32.
b. Zero the reticle. See Reset Zeroing Distance Menu > Reticle
Zeroing on page33 for detailed reticle zeroing menu
instructions.
