1. OVERVIEW
The InfiRay Outdoor BOLT SE is built on the success of previous BOLT
models with a focus on simplicity and ease of use. Designed with users
of traditional rifle scopes in mind, the BOLT SE oers a familiar profile
and tactile controls. InfiRay’s industry-leading 12 μm 384×288 MicroII
sensor, paired with a 1536×1080 AMOLED display provides exceptional
clarity across all zoom levels. The scope’s magnification can be
quickly adjusted via an intuitive zoom ring. Hunters can appreciate the
ability to use common mounting systems or the included 30 mm rings
to mount on bolt-action rifles or other platforms. An internal battery
with USB-C charging eliminates the need to change batteries during
a hunt. Photo and video recording with 32 GB of internal storage and
mobile app connectivity with wireless streaming allow users to share
their experiences with friends and family.
2. FEATURES
• 12 μm iRay Micro II thermal sensor
• <25 mK NETD sensor sensitivity
• 0.43-inch AMOLED display with ultra-high 1536×1080 resolution
• Aluminum alloy housing
• 1375-yard detection range
• Digital zoom from 1.0×to4.0×
• Low power consumption and long battery life
• Multiple zero profiles and ranges
• Traditional 30 mm diameter housing design
• High frame frequency: 50hz
• Compatible with ILR-1200-1 Bluetooth Laser Rangefinder
Module (optional/not included)
• Built-in 32 GB storage to support image capture and
video recording
• Built-in Wi-Fi module
• Mobile device App compatible
• Built-in digital compass and gravity sensor
• Multiple reticle types and color options
• Ultra-clear mode for advanced image detail
• Picture in Picture (PIP)
• Defective pixel correction
• Extended eye relief
• User-friendly interface
3. TECH SPECS
BOLTSE TL25 SE TL35 SE
SENSOR
Resolution 384×288
Pixel Size 12 μm
Frame Rate 50hz
Sensor Sensitivity <25 mK
Image Processing MATRIX III
Core InfiRay Micro II
OPTICS
Objective Lens 25 mm f/1.0 35 mm f/0.9
Magnification 2.0× 3.0×
Digital Zoom 4× 3.0×
Field of View 10.5° × 7.9° 7.5° × 5.7°
Detection Range 1375 Yards 1750 Yards
Display Type 0.43-inch AMOLED
Display Resolution 1536×1080
Color Palettes White Hot, Black Hot, Red Hot, Color, Highlight
Reticle Types 6 (1 Dynamic, 5 Static)
Reticle Colors Black, White, Red, Green
Mounting System 30 mm Rings
P.I.P Yes
Rangefinder Bluetooth ILR-1200-1 LRF (Optional/Not Included)
Eye Relief 50 mm
Diopter Range -5 to +4
ELECTRONICS
Onboard Recording Video, Recoil-Activated Video, and Image
Onboard Storage 32 GB
Wireless Connectivity Video and Image via App
Data/Power Connector USB-C
Power Supply USB-C External, Built-In Battery Pack (8+ Hours)
Start Up Time <10 Seconds, Instant from Standby
PHYSICAL
Size 12.20” × 2.76” × 2.76”
Weight 25.40 Oz
ENVIRONMENTAL/WARRANTY
Warranty 5 Years
Housing Material Aluminum Alloy
Ingress Protection IP67
Operation Temperature -4°F
~
122°F
Max. Recoil 1000 g/s² (300 Win./7mm Mag)
