4. Installation

4.1. Safety Instructions for Installation

WARNING

Incorrect installation can cause serious injuries and damage of property.

If trussing systems are used, installation must be carried out only by instructed or skilled persons.

Follow all applicable European, national and local safety regulations concerning rigging and trussing.

4.2. Personal Protective Equipment

During installation, deinstallation and rigging wear personal protective equipment in compliance with the

national and site-specific regulations.

4.3.

Installation Site Requirements

• The device can be used indoors and outdoors.•

• The minimum distance between the light output and the illuminated surface must be bigger than2 m.•

• The minimum distance to other objects must be bigger than 0,5 m.•

• The maximum ambient temperature t

= 45 °C must never be exceeded.•

4.4.

Rigging

The device can be positioned on a flat surface or mounted to a truss or other rigging structure in any

orientation. Make sure that all loads are within the pre-determined limits of the supporting structure.

CAUTION

Restrict the access under the work area during rigging/derigging.

To mount the device, follow the steps below:

01) Fasten the 2 quick-lock brackets, supplied with the device, on the mounting holes for quick-lock01)

brackets(17). You can position the quick-lock brackets in 4 ways.

02) Lock the 2 quick-lock brackets by turning the locking mechanism of the quick-lock brackets clockwise.02)

Figure 6

03) Install the clamps. Make sure that you use clamps suitable for attaching the device to a truss.03)

Product code: 41440

Furion W402 WashBeam
