5.3.4. DMX Addressing
In a setup with multiple devices, make sure that you set the DMX starting address of each device correctly. The
Furion S402 Spot has 3 personalities: Basic (25 channels), Advanced (35 channels) and User (35 channels).
If you want to connect multiple devices on one data link and use them in 35-channel mode, for example,
follow the steps below:
01) Set the starting address of the 1
st
device on the data link to 1 (001).01)
02)
Set the starting address of the 2
nd
device on the data link to 36 (036), as 1 + 35 = 36.
02)
03)
Set the starting address of the 3
rd
device on the data link to 71 (071), as 36 + 35 = 71.
03)
04)
Continue assigning the starting addresses of the remaining devices by adding each time 35 to the previous
04)
number.
Make sure that you do not have any overlapping channels in order to control each Furion S402 Spot correctly.
If two or more devices are addressed similarly, they will work similarly.
5.4. Wireless Connection
The device is equipped with a 2,4 GHz wireless receiver from LumenRadio. The W-DMX receiver is compatible
only with other W-DMX devices. It can be paired only with transceivers and transmitters with a W-DMX module.
Communication distance Depending on the transmitting power or transmitter module
Test conditions WDMX TRx Transmitter module, 2 dBi Antenna, transmitting power 20dBm (100 mW)
Range indoor 60 m
Range outdoor 250 m
Recommended transceiver: 51503 Lumenradio Stardust (G3, G4s, CRMX)
To connect multiple devices via wireless DMX, follow the steps below:
01) Set the devices to receive wireless DMX signal, refer to Control Mode (see 6.7.4. Control Mode on page01)
41).
02) Connect the transceiver/transmitter to the lighting controller.02)
03) Follow the user manual supplied with the transceiver to pair the devices.03)
Figure 16
22
c
Product code: 41450
Furion S402 Spot
