Local air conditioner/User Manual

33 / EN

Before starting operations in this section:

1) Find a place where there is power supply

nearby.

2) As shown in Fig.2 and Fig.2a, install the

exhaust hose, and adjust the window position

well.

Fig. 2

3) As shown in Fig. 6, connect drain hose well

(only for using heating model);

4) Insert the power cord into a grounded

AC220~240V/50Hz‹ socket;

conditioner.

1.

Fig. 2a

5) Press the POWER button to turn on the air-

Before using

Checkup whether the exhaust hose has been

mounted properly.

Cautions for cooling and dehumidifying

operations:

- When using functions on cooling and

dehumidifying, keep an< interval of at least

3 minutes between each POWER.

- Power supply meets the requirements. The

socket is for AC use.

- Do not share one socket with other

appliances.

- Power supply is AC220-240V, 50Hz

2. Cooling operation

- Press the “Mode” button till the “Cool’ icon

appears.

- Press the “ “ or “ “ button to select a

desired room temperature. (16°C-31°C)

C

Note:

Operation temperature range:

Maximum cooling Minimum cooling

DB/WB(°C) | 35/24 18/12

Maximum heating Minimum heating-

DB/WB(°C) | 27/--- 7/---

6 Operation introduction
