OPERATING INSTRUCTIONS
DOOR REVERSAL INSTRUCTIONS
If the appliance is placed on its back or side during this process
it must be allowed to stand upright for 6 hours before plugging in
to avoid damage to internal components.
1. Remove the screw hole cover from the top left side of the
cabinet. Remove the upper hinge cover and the upper hinge
from the top right side of the cabinet. Remove the refrigerator
door from the cabinet
2. Remove the center hinge from the right side of the cabinet.
Remove the freezer door from the cabinet. Remove the
screw hole covers from the left side of the cabinet. Remove
the freezer door from the cabinet.
3. Remove the lower hinge from the bottom right side of the
cabinet.
4. Remove the pin shaft to the right hole on the lower hinge,
then insert the pin shaft into the left hole on the lower hinge.
5. Install the lower hinge onto the lower left side of the cabinet.
6. Remove the freezer door stop from the lower right side to the
left side of the door. Remove the refrigerator door stop from
the lower right side to the left side of the door.
7. Move the door bushing from the top right side of the refrige-
rator door and remove the hinge hole cover from the top left
side of the door. Exchange their positions.
8. Install the freezer door onto the cabinet. Install the center
hinge on the left side of the cabinet. Install the screw hole
covers on the right side of the cabinet.
9. Install the refrigeratordoor onto the cabinet. Install the upper
hinge on the top left side of the cabinet. Install the screw hole
cover onto the top right side of the cabinet.
Note: These instructions reference the models that come from
the factory with a right hand swing door. If your appliance comes
with a left hand swing, ensure that you ip the “left” and “right’ in
these instructions.
