EN / 5
1708 mm
574 mm 30 mm
• Make sure that the mains cable is not caught under the appliance during and after moving, as this could
damage the cable.
• Do not allow children to play with the appliance or tamper with the controls. INDESIT declines to accept
any liability should the instructions not be followed.
INSTALLATION INSTRUCTIONS
1. The space in the room where the appliance is installed must not be smaller than 10 cubic metres.
2. Do not put your fridge freezer in a cold room where the temperature is likely to go below +10 degrees C
(50 degrees F) during night-time and/or especially in winter. This fridge freezer has been designed to
operate in ambient temperatures between +10 and +38 degrees C (50 and 100 degrees F). Therefore, if
the appliance is installed in an unheated/cold room (e.g.: conservatory / annex / shed / garage etc.) then
the appliance will not operate causing the freezer compartment to run warmer and as a result the storage
time of frozen food may be reduced.
3. Do not place the appliance near cookers, radiators or in direct sunlight as this will cause your appliance to
work harder. If installed next to a source of heat or freezer, maintain the following minimum side clearances:
From Cookers 2"
(
50 mm
)
From Radiators 12"
(
300 mm
)
From Refri
g
erators or Larder Frid
g
e 1"
(
25 mm
)
4. Make sure that sufficient room is provided around the appliance to ensure free air circulation (see diagram).
5. Fit the two plastic wall spacers supplied with the appliance rotating
1/4 turn to the condenser at the back of the refrigerator (see diagram).
6. The fridge/freezer should be located on a smooth surface. The two
front feet can be adjusted as required. To ensure that, your appliance
is standing upright adjust the two front feet by turning clockwise or
anti-clockwise, until the product is in firm contact with the floor.
Correct adjustment of feet avoids excessive vibration and noise.
7. Refer to “CLEANING AND CARE” section to prepare your appliance for use.
WARNING!
Do not connect your appliance to the electricity supply until all the
packing and transit protectors have been removed including
polystyrene block(s) inserted between the compressor motor and the
cabinet (see diagram). Do not remove the plastic drain tray fitted
above the compressor motor on models with auto-defrost fridge.
8. To take out the baskets from the freezer compartment please proceed as in item:
