14
USER MANUAL
Step 6: Fix the holder to the dryer machine. Place the unpackaged dryer machine on the floor. Unscrew the two
screws at the back of the machine with a cross screwdriver. Take out the holder in the kit. Press the screws into
the holes on the holder and then fasten them into the original screw holes. When hang upside down, Fix the
holder at the position of the two screws.
Caution! Weight Hazard.
Two or more people required to lift and install the dryer.
Figure 6- Placement for the dryer holders.
Step 7: Lift the dryer machine with two persons and direct the slots at the back of the washing machine to the
hooks. Then insert the hooks with some force to the slots.
Figure 7- Placement for the dryer hooks.
Step 8: When all installation procedures are finished,
test the machine by powering it on.
Important! Please ensure that the dyer is only ever installed in an
internal environment only (and not outside), or an environment where
the dryer could become wet. Never place the dryer near combustible
surfaces (such as curtains) and ensure the dryer isn’t operating near
gas or other flammable materials. Refer to Safety Instructions within
this user manual.
Installation Instructions (Cont.)
Wall Hanging Installation Manual
1. Accessories include components:
hooks (2), holders (2), expansion bolts (4), installation
positioning paper (1), and installation manual (1).
Hook
Holder
Expansion
Bolt
Installation
Positioning Paper
When hang
straight,Hang the
hooks into the
two holes.
When hang
upside down,
Hang the hooks
into these two holes.
When hang upside
down, Fix the holder
at the position of the
two screws.
When hang straight,
Fix the holder at the
position of the two
screws.
(Applicable to 6kg and 7kg models)
Wall Hanging Installation Manual
1. Accessories include components:
hooks (2), holders (2), expansion bolts (4), installation
positioning paper (1), and installation manual (1).
Hook
Holder
Expansion
Bolt
Installation
Positioning Paper
When hang
straight,Hang the
hooks into the
two holes.
When hang
upside down,
Hang the hooks
into these two holes.
When hang upside
down, Fix the holder
at the position of the
two screws.
When hang straight,
Fix the holder at the
position of the two
screws.
(Applicable to 6kg and 7kg models)
