09
Installation Instructions (Continued)
WARNING!
To prevent leakage or water damage, follow the
instructions in this chapter carefully:
• Do not kink, crush, modify, sever or protract the inlet
hose or drain hose.
• Position drain hose properly, otherwise damage might
result of water leakage.
• If drain hose is too long, do not force it into washing
machine as it will cause abnormal noises.
Use an upper drain system to place the end
of drain hose:
Selection of Tap
Please select appropriate tap
Ordinary faucet Screw tap Specialised
washing
machine tap
Connection of the Inlet Hose,
Tap and Washing Machine
Connection between ordinary tap and inlet hose.
1. Loosen the clamp nut until approximately 5mm of
thread is visible.
2. Loosen the four mounting bolts on the connector.
3. Position the connector base over the tap and
tighten the bolts evenly to secure it in place.
4. Tighten the clamp nut firmly to ensure a secure fit
around the tap.
5. Press the slide bushing on the inlet hose and insert
the hose into the connector base.
