10
Positioning the Appliance
When positioning the appliance in your desired location,
the back should rest against the wall behind it, and the
sides should be along the adjacent cabinets or walls.
The dishwasher is equipped with water supply and drain
hoses that can be positioned either to the right or the
left sides to facilitate proper installation.
The installation position of dishwasher should be near
the existing inlet and drain hoses and power cord.
IMPORTANT:
• Less than 5 mm between the top of dishwasher and
cabinet and the outer door aligned to cabinet.
• If dishwasher is in stalled at the corner of the cabinet,
there should be some space when the door is opened.
• Depending on where your electrical outlet is, you may
need to cut a hole in the opposite cabinet side.
Freestanding Installation
Fitting between existing cabinets
The height of the dishwasher, 845 mm, has been
designed in order to allow the machine to be fitted
between existing cabinets of the same height in modern
fitted kitchens.
The feet can be adjusted so that correct height is
reached.
The laminated top of the machine does not require
any particular care since it is heatproof, scratch proof
and stain proof.
Built-in Installation
Fitting underneath a benchtop
In most modern fitted kitchens there is only one
single bench top under which cabinets and electrical
appliances are fitted. In this case remove the work top
of the dishwasher by unscrewing the screws under the
rear edge of the top (a).
ATTENTION: After removing the work top, the screws
must be screwed again under the rear edge of the top
(b).
The height will then be reduced to 815 mm, as
scheduled by the International Regulations (ISO) and
the dishwasher will fit perfectly under the kitchen
working top.
600mm
Space between cabinet
bottom and floor
Electrical, drain
and water supply
line entrances
580mm
100mm
80mm
820mm
90° 90°
Installation Instructions (Continued)
CabinetryDishwasher
Dishwasher
Door
Minimum Space
of 50mm
