USER MANUAL PAGE 08
INSTALLATION INSTRUCTIONS
It’s important to carefully read the following
installation instructions before beginning the installation
of your cooktop.
IMPORTANT!
The installation must be carried out by a suitably qualified
and authorised person, in accordance with the current
version of the following:
► AS/NZS5601.1 Gas Installations: current edition
► NZS 5261: Code of Practice for the Installation of Gas
Burning Appliances and Equipment (New Zealand)
► Local gas fitting regulations
► AS/NZS 3000: Electrical Installations (Wiring Rules)
► Building codes
► Installation Instructions
POSITIONING
The adjacent cabinetry and wall materials must be able
to withstand a minimum temperature rise of 65° C above
the ambient temperature of the room.
► This appliance has been designed for use within
a kitchen.
IMPORTANT!
The cooktop must not be installed in a bathroom or
shower room.
This appliance is classified as Class 3 and therefore is to
be built into a kitchen unit (depending on size) or 600mm
deep worktop, providing the minimum distances in the
following list are allowed.
A Minimum distance from the edge of the closest
burner (left and/or right side) to the nearest vertical
combustible surface: 200mm*
B Minimum distance from the edge of the closest rear
burner to the combustible vertical surface: 200mm*
C Minimum height of noncombustible material when
used on adjacent walls: 200mm
D Minimum clearance from top of highest burner cap
to rangehood: 600mm**
E Minimum clearance below top of bench top to nearest
combustible surface: 70mm
F Ensure there is an earthed power outlet within 900mm
of the rear right-hand corner of the cooktop. The outlet
should be accessible with the cooktop installed.
G If connecting the cooktop to the gas supply with a
flexible hose, the connector on the wall should be
between 800–850mm above the floor and to a distance
of at least 250mm outside the width of the cooktop.
The connector should be accessible with the cooktop
installed.
* Where the clearance is less than 200mm the surface
must be protected by a non-combustible material
(I.e. ceramic tiles) for a minimum height of 200mm
(see Fig. 1).
** For any flammable objects (I.e. utensil rails, wall
cabinets, shelves, etc.) a minimum clearance of at least
600mm above the burner cap must be maintained
between them and the cooktop below.
Installation Instructions
FIG. 1
