5
If the unit is to be installed with casters, a flexible connector must be used and the same ANSI standards
apply. Locking front casters are provided to limit the movement of the appliance without depending on the
connector or associated piping. A suitable strain relief must be installed with the flexible connector.
All connections must be sealed with a joint compound suitable for LP gas and all connections must be
tested with a soapy water solution before lighting pilots.
INITIAL PILOT LIGHTING
All Imperial Mfg. appliances are adjusted and tested before leaving the factory, effectively matching them
to sea level conditions. Adjustments and calibrations to assure proper operation may be necessary on installation to
meet local conditions, low gas characteristics, to correct possible problems caused by rough handling or vibration
during shipment, and are to be performed only by qualified service personnel. These adjustments are the
responsibility of the customer and/or dealer and are not covered by our warranty.
Check all gas connections for leaks with a soapy water solution before lighting any pilots. DO NOT USE
AN OPEN FLAME TO CHECK FOR LEAKS! Putting an open flame beside a new gas connection is extremely
dangerous. Before lighting any pilots, make sure that burner valves and thermostats are turned “off”.
A. TOP BURNER/RAISED GRIDDLE-BROILER
All top section burners are equipped with constant-burning pilots. These are to be manually lighted
immediately after the gas is turned on and the system is checked for leaks. Burner pilots are proved for each
burner and can be rechecked for proper adjustment. Adjustments can be made with a screwdriver to the brass
pilot valve accessible through the valve cover.
B. HOT TOP
The pilot should be lighted immediately after the gas is turned on and the system is checked for leaks. The
pilot can be reached with a long match through the valve cover, or by lifting the plate upward and accessing
through the top.
C. GRIDDLES
The griddle pilot is ignited in the same fashion as the Hot Top section, using a long lighted match placed
through the front control panel opening. Adjustment of the pilot flame can be made with a screwdriver to the
pilot valve, accessible through the valve cover.
For detailed service instructions to adjust by-pass (minimum burner) flame and to recalibrate oven
and griddle thermostatic controls, see attachment at the end of this manual.
D. STANDARD OVEN
Pilot gas is tapped from the thermostat, routed through tubing to a pilot burner.
Oven pilot lighting or relighting is to be completed in the following sequence:
(1) Turn the oven thermostat knob to “off” and wait 5 minutes.
(2) Remove the oven’s lower kick plate by lifting up and out. This exposes the pilot burner.
(3) Make sure any accumulated gas has dispersed. Since propane gas is heavier than air, check near the
floor area for the odor of propane gas before attempting to light any pilot burners.
(4) Rotate thermostat to pilot position and depress and hold it in throughout the lighting procedure.
(5) Light pilot burner.
(6) Continue to depress the thermostat until the pilot remains lit when released.
(7) If pilot is extinguished, repeat steps 4 through 6 above.
CAUTION
When lighting pilots and checking for leaks, do not Stand with your face close to the combustion chamber
