16
BURNERS OF THE TOP
- Replacement of the injectors
Procedure: SR - R - P • small solid top burner
• Remove the grill and the burners from the hob.
• Burners SR – R – P :
SR – R – P burners: unscrew injectors “U” using a 7 mm
spanner (g. 1) and replace them with those for the
new gas according to table number 2 on page 15.
Save the orices removed from the appliance for fu-
ture use.
Procedure: DUAL
• Remove the grill and the burners from the hob.
• Unscrew injectors “U” using a 7-mm spanner (g. 8, g
10) and replace them with those for the new gasac-
cording to table number 3. Save the orices removed
from the appliance for future use.
Procedure: DCC
• DCC – Dual burners: unscrew the 2 screws “P” and
remove cover “C” g.2.
• unscrew injectors “U” using a 7 mmspanner (g.3,
g.4) and replace them with those for the new gas
according to table number 1 below 13. Save the
orices removed from the appliance for future use.
2
4
U
U
1
2
U
U
1
U
3
PP
CC
PP
