USER
9
INSTRUCTIONS FOR USE
ON-OFF
Turns on and off the engine at speed 1.
Speed 1
Puries the air whilst limiting electricity consumption.
24-hour air recirculation
Hold down the “0/1” button for 7 seconds to turn the air recirculation program on or off
(alternating operations for 24 hours: off 20 minutes and 5 minutes in rst speed).
Speed 2
Normal conditions of use.
Speed 3
For the elimination of particularly intense fumes and smells (e.g: when frying or grilling).
Dynamic speed
Starts the motor at maximum speed for 5 minutes and then automatically returns to
speed 3.
Auto switch-off
To activate the auto switch-off, the hood must be switched on and then the “light con-
trol” key must be pressed for 5 seconds until all the LEDs begin to ash, by subsequently
pressing one of the keys (0/1, 2, 3, ) the auto switch-off time can be programmed
which will differ according to the key pressed:
0/1 = 5’, 2 = 10’, 3 = 15’, = 20’. During the auto shut-off time, it is possible to chan-
ge the set speed. During the auto shut-off, the LED corresponding to the chosen time
ashes.
Light button
Turns the light on and off.
Infrared lamp control
Press the key once to turn on the left lamp
Press the key twice to turn on the right lamp
Press the key 3 times to turn off the lamps
Filter timer
After 30 hours of hood operation, when the hood is switched off, all the LEDs will light up
with a xed light for 30 sec. to advise the necessary cleaning of the aluminium lters. The
key, held down for a long time with the extractor off, will reset the timer. If this key is
not pressed, the same operation will come up once the hood is switched off again. This
procedure will be repeated for the next 30 hours until it reaches 120 hours of operation.
At the end of 120 hours, when the hood is switched off, all the LEDs will ash for the next
30 seconds to remind you to clean the aluminium lters and, if the hood is ltering, to
replace the active carbon lters. Once the timer has been reset (still with the key held
down for a long time with the extractor off) the whole process will re-occur after the next
30-hours of extraction.
CONTROL PANEL
0/1
2 3
0/1
2 3
0/1
2
3
0/1
2
3
0/1
2 3
0/1
2 3
0/1
2 3
Fig. 3
