14 ENGLISH
5. SPECIFICATIONS
Model: TILLREDA 905.464.78
Rated Voltage: 120VAC, 60Hz
Rated Input Power
(Microwave):
900W
Rated Output Power
(Microwave):
700 W
Oven Capacity: 20 L
Turntable Diameter: 255 mm
External Dimensions: 439.5x340.0x258.2mm
Net Weight: around 10.6 kg
6. INSTALLATION AND CONNECTION
Countertop Installation
Remove all packing material and accessories. Examine
the oven for any damage such as dents or broken
door. Do not install if oven is damaged.
Cabinet: Remove any protective lm found on the
microwave oven cabinet surface. Do not remove the
white plastic cover that is attached to the oven cavity
to protect the magnetron.
Installation
1. Select a level surface that provide enough open
space for the intake and/or outlet vents.
(1) The rear surface of appliance shall be placed
against a wall. Leave a minimum clearance of
11.5 cm above the oven, a minimum clearance of 8
cm is required between the oven and any adjacent
walls.
(2) Do not remove the legs from the bottom of the
oven.
(3) Blocking the intake and/ or outlet openings can
damage the oven.
(4) Place the oven as far away from radios and TV as
possible. Operation of microwave oven may cause
interference to your radio or TV reception.
2. Plug your oven into a standard household outlet. Be
sure the voltage and the frequency is the same as
the voltage and the frequency on the rating label.
WARNING: Do not install oven over a range cooktop
or other heat-producing appliance. If installed near or
over a heat source, the oven could be damaged and
the warranty would be void.
The accessible surface may be hot during
operation.
