• Thespacebetweenthecabinetsmustbe30"(76.2cm)
wide and free of obstructions.
• Ifyouaregoingtoventyourmicrowaveoventothe
outside, see Hood Exhaust Section for exhaust duct
preparation
• Wheninstallingthemicrowaveovenbeneathsmooth,
atcabinets,becarefultofollowtheinstructionsonthe
top cabinet template for power cord clearance.
Template Information.
•
1 PLACEMENT OF THE MOUNTING
PLATE
A. REMOVING THE MICROWAVE OVEN FROM
THE CARTON/ REMOVING THE MOUNTING
PLATE
1. Remove the installation instructions,use and care,
exhaustadapter,turntablering,shelf,lters,glass
tray and the small hardware bag. Do not remove the
Styrofoam protecting the front of the oven.
16 ½"
2" (5.1 cm)
66"
(167.6 cm)
or more from the
floor to the top of
the microwave
30"
(76.2 cm)
min.
Backsplash
¼" Min
Clearance
Exhaust Adapter
Shelf (For some
models)
Glass Tray
Filters and Turntable
Ring below glass tray
2.Foldbackall4cartonapsfullyagainstcartonsides.
Then carefully roll the oven and carton over onto the
top side. The oven should be resting in the Styro-
foam.
Mounting Space
(41.9 cm)
13" (33cm) recommend ed
Fitting Bag
If the cabinet depth, including the cabinet doors, is
from wall using adequate materials supporting 150 lbs
to allow proper top vent air exhaust/intake.
Outside exhaust or
recirculating when
cabinet depth <13”
< 13”
< (33cm)
¼” min
clearance
Cabinet
> 13”
> (33cm)
Spacer is
needed
Cabinet
¼”
min
clearance
5
EN
then the unit must be spaced out
• Asaguidetoinstallation,seepage22forMounting
Outside exhaust or
recirculang when
cabinet depth >13"
more than 13",
