8ENGLISH
Setting the water hardness
To allow the water softener to work in a perfect way, it is
essential that the water hardness setting is based on the actual
water hardness in your house. This information can be obtained
from your local water supplier. The factory sets the default value
for the water hardness.
• Switch on the appliance by pressing the ON/OFF button.
• Switch o the appliance by pressing the ON/OFF button.
• Hold down button
for 5 seconds, until you hear a beep.
• Switch on the appliance by pressing quickly the ON/OFF
button.
• The program indicator light of the current set level ashes.
• Press button to select the desired hardness level (see
WATER HARDNESS TABLE).
• Switch o the appliance by pressing the ON/OFF button.
Setting is complete!
Water Hardness Table
Level °dH German
degrees
°fH French
degrees
°Clark English
degrees
1 Soft 0 - 6 0 - 10 0 - 7
2 Medium 7 - 11 11 - 20 8 - 14
3 Average 12 - 16 21 - 29 15 - 20
4 Hard 17 - 34 30 - 60 21 - 42
5 Very hard 35 - 50 61 - 90 43 - 62
Water Softening System
Water softener automatically reduces water hardness, conse-
quently preventing scale buildup on heater, contributing also
to better cleaning eciency. This system regenerates itself with
salt, therefore it is required to rell salt container when empty.
Frequency of regeneration depends on water hardness level
setting - regeneration takes place once per 6 Eco cycles with
water hardness level set to 3.
Regeneration process starts in nal rinse and nishes in drying
phase, before cycle ends.
• Single regeneration consumes: ~3.5 L of water;
• Takes up to 5 additional minutes for the cycle;
• Consumes below 0.005 kWh of energy.
Filling the rinse aid dispenser
Rinse aid makes dish DRYING easier. The rinse aid dispenser
A
should be lled when when the dark optical indicator on the
dispenser door
C
becomes transparent.
1. Open the dispenser
B
by pressing and pulling up the tab on
the lid.
2. Carefully introduce the rinse aid as far as the maximum (110
ml) reference notch of the lling space - avoid spilling it. If this
happens, clean the spill immediately with a dry cloth.
3. Press the lid down until you hear a click to close it.
NEVER pour the rinse aid directly into the tub.
B A
C
Adjusting the dosage of rinse aid
If you are not completely satised with the drying results, you
can adjust the quantity of rinse aid used.
• Switch the dishwasher on using the ON/OFF button.
• Switch it o using the ON/OFF button.
• Press button three times - a beep will be heard.
• Switch it on using the ON/OFF button.
• The program indicator light of the current set level ashes.
• Press button to select the level of rinse aid quantity to be
supplied.
• Switch it o using the ON/OFF button.
Setting is complete!
If the rinse aid level is set to 1 (ECO), no rinse aid will be
supplied. The LOW RINSE AID indicator light will not be lit if you
run out of rinse aid. A maximum of 5 levels can be set according
to the dishwasher model. The factory setting is specic to the
model, please follow instruction above to check this for your
machine.
• If you see bluish streaks on the dishes, set a low number (2-3).
• If there are drops of water or limescale marks on the dishes,
set a high number (4-5).
Filling the detergent dispenser
Usage of detergent not designed for dishwashers may cause
malfunction or damage to the appliance.
To achieve the best washing and drying results, the combined
use of detergent, rinse aid liquid and rened salt is required.
We recommend using detergents that do not contain
phosphates or chlorine, as these products are harmful to the
environment.
Good washing results also depend on the correct amount of
detergent being used.
Exceeding the stated amount does not result in a more eective
wash and increases environmental pollution.
The amount can be adjusted to the soil level. In the case of
normally soiled items, use approximately either 35g (powder
detergent) or 35ml (liquid detergent) and additional tea spoon
of detergent directly inside the tub. If tablets are used, one
tablet will be enough.
If the crockery is only lightly soiled or if it has been rinsed
with water before being placed in the dishwasher, reduce the
amount of detergent used accordingly (minimum 25 g/ml) e.g.
skip the powder/gel putted inside the tub.
To open the detergent dispenser press button
D
.
Introduce the detergent into the dry dispenser
E
only.
Place the amount of detergent for pre-washing directly
inside the tub.
1. When measuring out
the detergent refer to
the mentioned earlier
information to add the
proper quantity. Inside
the dispenser
E
there are
indications to help the
detergent dosing.
2. Remove detergent
residues from the edges
of the dispenser and
close the cover until it
clicks.
3. Close the lid of the detergent dispenser by pulling it up until
the closing device is secured in place.
The detergent dispenser automatically opens up at the right
time according to the program.
D
