63
Center line
Filler blocks
h Tape the template to the bottom of the cabinet.
i Drill 3/8 in. holes through the template at points A and B for LAGAN, SKALLEBO
and SOLNEBO (points A, B and E for YGSBO)
CAUTION: Wear safety goggles when drilling holes in the cabinet bottom.
j Cut a 2 in. (5 cm) diameter hole at point C for the power cord.
k Remove the template.
I If you have recessed cabinets:
• Make two filler blocks out of scrap wood pieces the size of shaded areas F and G
They must be as thick as the depth of the cabinet recess.
• Drill 3/8 in. holes in the filler blocks to align with points A and B.
• Align the blocks with the corresponding holes in the cabinet. They should be at
the same level as the bottom edge of the cabinet frame.
ENGLISH
Ligne centrale
Blocs de remplissage
Línea central
Bloques de revestimiento
