ENGLISH
APPENDIX 31
APPENDIX
Designandspecicationsaresubjecttochangewithoutpriornotice.
Size Category 22"
LCD
Panel
Panel technology
IPS(In-Plane-Switching)
Size Diagonal:21.45"(54.5cm)
Pixel pitch 0.249mm H × 0.241mm V
Brightness 300cd/m
2
(Typical),165cd/m
2
(Default/EnergySaving)
Contrast ratio 1000:1(Typical),Adv.ContrastFunctionAvailable
Viewable angle
Right/Left:89degreeseach,Up/Down:89degreeseach(Typical)
MPRT 1ms
Display Colors Approx. 16.7M
Sync Frequency
HDMI(AdaptiveSync:O):
Horizontal: 30.0-110.0kHz, Vertical: 55-100Hz
HDMI(AdaptiveSync:On):
Horizontal: 30.0-110.0kHz, Vertical: 48-100Hz
DisplayPort(AdaptiveSync:O):
Horizontal: 30.0-110.0kHz, Vertical: 55-100Hz
DisplayPort(AdaptiveSync:On):
Horizontal: 30.0-110.0kHz, Vertical: 48-100Hz
Native Resolution 1920 × 1080, 2.1 MegaPixels
Support max. resolution
HDMI(AdaptiveSync:O):1920×1080,100Hz
HDMI(AdaptiveSync:On):1920×1080,100Hz
DisplayPort(AdaptiveSync:O):1920×1080,100Hz
DisplayPort(AdaptiveSync:On):1920×1080,100Hz
Input Connector HDMI, DisplayPort
Input Video Signal HDMI, DisplayPort
USB Standard USB2.0(DC5V,500mA)
Number of USB Ports
Connector shape
1 Upstream : Series B
2 Downstream : Series A
Headphone Connector *
1
ø3.5mmminijack(Stereo)
Speakers 2W×2(Stereospeakers)
Maximum Screen Size 478.66mm W × 260.28mm H / 18.84" W × 10.25" H
Power Source 100-240VAC, 50/60Hz, 1.5A
Power Consumption *
2
17W typical
Standbymode:0.5Wmaximum,Omode:0.3Wmaximum
Dimensions / Net Weight
492.0×328.5-478.5×209.5mm/19.4×12.9-18.8×8.2"(W×H×D)
3.9kg / 8.60lbs
Height Adjustment Range 150mm
Angle
Tilt: Upward: 23 degrees, Downward: 5 degrees
Swivel: Left / Right: 60 degrees each
Rotation: Clockwise / Counterclockwise: 90 degrees each
Environmental
Considerations
Operating:
Storage:
Temperature
Humidity
Temperature
Humidity
5 to 35°C / 41 to 95°F
10to80%(Nocondensation)
-20 to 60°C / -4 to 140°F
10to90%(Nocondensation)
EPEAT Bronze Visit www.epeat.net for the registration status in your country
Approvals TCOCertied,CE, UKCA, TÜV-Bauart, VCCI, PSE, EAC
SPECIFICATIONS : ProLite XUB2293HSU-B7 / ProLite XUB2293HSU-B7 A
NOTE
*
1
Proper operation of connected external devices other than headphones is not guaranteed.
*
2
When the USB devices are not connected.
