ENGLISH
16 APPENDIX
*¹ USB C support only mirroring mode in video output, touch mode only support Win 10
and 11 Operating System.
*² When the USB devices are not connected.
NOTE
SPECIFICATIONS : ProLite TW3226AS-B3P
Touch
Screen
Technology Proejctive Capacitive 10pt touch
Hardness > 6H
Size Category 31.5"
Panel
Panel technology VA
Size Diagonal: 80.1cm (31.5")
Pixel pitch 0.36375mm H ×0.36375mm V
Brightness 500cd/m
2
(Typical) , 430cd/m
2
(with Touch panel)
Contrast ratio 4000:1 (Typical)
Viewable angle Horizontal : 178 degrees, Vertical: 178 degrees (Typical)
Response time 8ms (Gray to Gray)
Surface Treatment Anti-Glare, Haze 25%, Hard Coating(3H)
Display Colors Approx. 16.7M
Maximum Resolution 1920 × 1080, 2 MegaPixel
SOC Rockchip RK3576 Octo-core, up to 2.2GHz
GPU ARM G52 MC3
Storage 32GB eMMC
Memory 4GB × LPDDR4X
Wi-Fi LAN 802.11ax/ac/a/b/g/n 10M/100M/1000M
Bluetooth 5.3
Microphone Standard Quad Microphone
External IO Port *¹
LAN (RJ45) × 1, USB3.2 Gen 1 (5Gbps, DC5V, 900mA) × 1,
USB2.0 (DC5V, 500mA) × 1,
HDMI (input, 1920×1080 60Hz) × 1,
USB C (DC5V, 900mA, video output only, touch board function) × 1,
Microphone (ø3.5mm mini jack) × 1
OS version Android 14
Speakers 5W × 2 (Stereo speakers)
Maximum Screen Size 698.4mm W × 392.8mm H / 27.4" W × 15.4" H
Power Source 12VDC, 5.0A
Power Consumption *² 36.34W typical
Dimensions / Net Weight
735.0 × 436.0 × 35.0mm / 28.9 × 17.1 × 1.3" (W×H×D)
7.71kg / 17 lbs (Excluding the AC Adapter)
Environmental Considerations
Operating:
Storage:
Temperature
Humidity
Temperature
Humidity
0 to 40°C / 32 to 104°F
10 to 80% (No condensation)
-20 to 60°C / 14 to 140°F
10 to 90% (No condensation)
Approvals CE, UKCA, EAC
APPENDIX
Design and specications are subject to change without prior notice.
