ENGLISH
APPENDIX 19
APPENDIX
Design and specications are subject to change without prior notice.
*
USB peripherals are not connected.
NOTE
Touch
Screen
Technology Projected capacitive 10pt touch
Light transmission 86%
Hardness >6H
Thickness 1.85mm
Size Category 10.1"
LCD
Panel
Panel technology IPS
Size Diagonal: 10.1" (25.5cm)
Pixel pitch 0.1692mm H × 0.1692mm V
Brightness 450cd/m
2
(Typical), 390cd/m
2
(with Touch panel)
Contrast ratio 1000 : 1 (Typical: with Touch panel)
Viewable angle Horizontal : 160 degrees, Vertical: 160 degrees (Typical)
Response time 25ms (Gray to Gray)
Display Colors Approx.16.7M
Maximum Resolution 1280 × 800, 1 MegaPixel
SOC Rockchip RK3399 Dual-core, up to 1.8GHz
GPU Dual core cortex A72 + Quad core cortex A53
Storage 32GB eMMC
Memory 4GB DDR4
Wi-Fi LAN IEEE802.11b/g/n 100M/1000M
Bluetooth 5.2
RFID 125khz, 9600kbit/s
NFC NXP PN7160
Webcam / Microphone 5 MegaPixel / Single Microphone
External IO Port
SD × 1, USB3.2 (USB3.2 Gen 1: 5Gbps, 5V, 900mA) × 1
USB2.0 (DC5V, 500mA) × 1, Mini USB OTG (DC5V, 500mA) × 1,
RJ45 (LAN) × 1 (PoE IEEE802.3af/15.4W),
Headset Microphone (ø3.5mm mini jack) × 1
OS version Android 12
Speakers 2W × 2 (Stereo speakers)
Maximum Screen Size 216.58mm W × 135.36mm H / 8.5" W × 5.3" H
Power Source 12VDC, 1.5A
Power Consumption * 10W typical
Dimensions / Net Weight
259.5 × 178.5 × 28.0mm / 10.2 × 7.0 × 1.1" (W×H×D)
1.1kg / 2.4lbs (Excluding the AC Adapter)
Environmental Considerations
Operating:
Storage:
Temperature
Humidity
Temperature
Humidity
0 to 40°C / 32 to 104°F
20 to 80% (No condensation)
-10 to 60°C / 14 to 140°F
10 to 90% (No condensation)
Approvals CE, UKCA, EAC
SPECIFICATIONS : ProLite TW1025LASC-B1PNR
