ENGLISH
APPENDIX 53
APPENDIX
Design and specications are subject to change without prior notice.
Touch
Screen
Technology IR Touch 40points
Light transmission
98%
Hardness 7H
Thickness 3.2mm
Response time 5ms
Size Category 86"
LCD
Panel
Panel technology
IPS
Size Diagonal: 85.6" (217.4cm)
Pixel pitch 0.4935mm H × 0.4935mm V
Brightness 550cd/m
2
(Typical, panel), 365cd/m
2
(Default / Energy Saving)
Contrast ratio 1200 : 1 (Typical: without glass)
Viewable angle Horizontal : 89 degrees, Vertical: 89 degrees (Typical)
Response time 8ms (Typical, Gray to Gray)
Display Colors Approx.1.07B
Sync Frequency
HDMI1/2: Horizontal: 30.0-135.0kHz, Vertical: 24-60Hz
DisplayPort / USB-C 3.2 Gen1: Horizontal: 30.0-135.0kHz, Vertical:
24-60Hz
Native Resolution 3840 × 2160, 8.3 MegaPixels
Supported max. resolution
HDMI1/2: 3840 × 2160 60Hz (YUV420/RGB444/YUV444)
DisplayPort / USB-C 3.2 Gen1: 3840 × 2160 60Hz
Input Connector HDMI ×2, DisplayPort ×1, USB-C ×1
USB Standard
USB2.0 (DC5V, 500mA) ×1
USB3.2 Gen 1 (5Gbps, DC5V, 900mA) ×2
Type C OUT 3.2 Gen 1 (5Gbps, 5V, 1A) ×1
Type C 3.2 Gen 1 (5Gbps, 5V, 3A / 9V, 3A / 15V, 3A / 20V, 3.25A /
20V, 5A) ×1
Number of USB Ports
Connector shape
2 Upstream : Type B (for touch)
3 Downstream : Type A
OPS 80PIN, 18V 5.3A, Max 95W
MIC IN Connector ø 3.5mm mini jack (Stereo)
Audio Out Connector *
1
ø 3.5mm mini jack (Stereo)
LAN RJ45 ×2 (in/out)
Serial Port RS-232C In
Input Video Signal Digital: HDMI, DisplayPort, USB-C 3.2 Gen1 (DisplayPort 1.2)
Input Audio Signal 2.0Vrms maximum
Output Connector
HDMI 3840 × 2160 60Hz
Type C OUT 3840 × 2160 60Hz
SPDIF out Connector
SPDIF
SPECIFICATIONS : ProLite TE8615A-B1AG
