ENGLISH
BEFORE YOU OPERATE THE MONITOR 11
Lock the screws.
Use a level to mount the wall mount horizontally on the wall with arrow facing up.
Extend the wall mount to maximum and unlock the Safety buckle to observe the alignment of
display back cover screws and bracket hook slots.
Hang the M6 screws into wall mount recesses, press the Safety buckle back, organize display
cables into the alignment slots.
Ø3*12 Screw
Backshell Cover
Wall
Wall
Landscape
Landscape
Portrait
Portrait
Backshell
Round Slot
Magnet
Safety Buckle
M6*8
screws
Ø5*60 screw
Ø5*60 screw
Ø5*60 screw
Expansion Plugs
Ø4*30 screw
Expansion Plugs
Magnet pad
Ø4*30 screw
Ø5*60 screw
Expansion Plugs
M6*8
screws
