ENGLISH
34 APPENDIX
APPENDIX
Designandspecicationsaresubjecttochangewithoutpriornotice.
SPECIFICATIONS : ProLite LH5551UHSB
*
When the USB devices are not connected.
NOTE
Size Category 55"
LCD
Panel
Panel technology
ADS
Size Diagonal:54.6"(138.8cm)
Pixel pitch 0.315mm H × 0.315mm V
Brightness 800cd/m
2
(Typical)
Contrast ratio 1200:1(Typical)
Viewable angle Horizontal:178degrees,Vertical:178degrees(Typical)
Response time 8ms(Typical,GraytoGray)
Display Colors Approx.1.07 G
Sync Frequency Horizontal: 15.0-160.0kHz, Vertical: 23-86Hz
Native Resolution 3840 × 2160, 8.3 MegaPixels
Support Max. Resolution 3840 × 2160 60Hz
Input Connector HDMI × 2, DisplayPort × 2
PC Slot Intel
®
SDM-L
LAN RJ45
Serial Port RS-232C In/Out RJ45
Input Video Signal Digital: HDMI, DisplayPort
IR Extender Connector
IR In/Out
USB Connector
USB2.0(DC5V,500mA)(ServicePort)×1
Output Connector DisplayPort × 1
Speakers Internal: 10W × 2(Stereospeakers)
Maximum Screen Size 1209.6mm W × 680.4mm H / 47.6" W × 26.8" H
Power Source 100-240VAC, 50/60Hz, 3.5A
Power Consumption*
183W typical,
Standbymode:0.5Wmaximum,Omode:0.3Wmaximum
Dimensions / Net Weight
1236.5×707.5×64.5mm/48.7×27.9×2.5"(W×H×D)
26.6kg / 58.6lbs
Environmental
Considerations
Operating:
Storage:
Temperature
Humidity
Temperature
Humidity
0 to 40°C / 32 to 104°F
20to80%(Nocondensation)
-20 to 60°C / 4 to 140°F
5to95%(Nocondensation)
Approvals CE, UKCA, EAC, TÜV-Bauart
