This function causes the pan or tilt positions to be automatically adjusted to the cor‐
rect position when they are twisted. To enable or disable this function, proceed as
follows:
1. Open the main menu.
2.
Navigate to ‘Fixture Settings è P/T Feedback’.
3. Use [UP] and [DOWN] ‘No’ (Tilt / Pan Feedback deactivated) or ‘Yes’ (Tilt / Pan
Feedback activated).
4. Conrm your selection with [ENTER].
ð
The “Tilt / Pan Feedback” function is activated or deactivated.
5. To exit the menu, press [MENU], or wait 30 seconds.
1. Open the main menu.
2.
Navigate to ‘Fixture Settings è Fan Mode’.
3. Use [UP] and [DOWN] to select ‘Auto’ (automatic speed) or ‘Silent’ (reduced
speed).
4. Conrm your selection with [ENTER].
ð
The fan mode is specied.
5. To exit the menu, press [MENU], or wait 30 seconds.
1. Open the main menu.
2.
Navigate to ‘Fixture Settings è Dimmer Curve’.
3. Use [UP] and [DOWN] to select one of the following settings:
n ‘Linear’ : The light intensity increases linearly with the DMX value.
n ‘Square Law’
: The light intensity is ner in the lower range, and can be
adjusted in the upper range.
n ‘Inv SQ Law’ : The light intensity is coarser in the lower range, and can be
adjusted in the upper range.
n ‘S Curve’
: The light intensity is ne in the upper and lower range, and can
be adjusted in the mid range.
4. Conrm your selection with [ENTER].
ð
The desired setting is saved.
5. To exit the menu, press [MENU], or wait 30 seconds.
1. Open the main menu.
2.
Navigate to ‘Fixture Settings è Dimmer Speed’.
3. Use [UP] and [DOWN] to select ‘Fast’ or ‘Smooth’ .
4. Conrm your selection with [ENTER].
ð
The dimmer speed is specied.
5. To exit the menu, press [MENU], or wait 30 seconds.
Activating or deactivating “Tilt / Pan
Feedback”
Specifying the fan mode
Specify dimming mode
Specify the dimmer speed
Operation
Gawan 200
15
Moving Head
