7.2 Main menu

If the display is in standby, unlock it: Successively press [UP], [DOWN], [UP], [DOWN]

and [ENTER].

Press [MODE] to activate the main menu. Use the buttons [UP] or [DOWN] to select a

submenu. When the display shows the desired submenu, press [ENTER] to open it. To

close the main menu, press [MODE].

If you do not press any key for about 30 seconds, the main menu will be reactivated

automatically.

All previously made settings are retained even when you disconnect the device from

the power grid. To restart with default values, use the function ‘Factory Reset’ .

The following table shows the setting options.

Main menu Menu level 2 Menu level 3 Menu level 4

Meaning

‘DMX Address’ ‘Set DMX address’ 001…512 Setting the DMX address

‘MODE’ ‘DMX Signal Select’ Selection of the DMX transmission type

‘DMX’ DMX via cable

‘Wireless DMX’ DMX via radio transmission

‘DMX Mode’ Selecting a DMX mode

‘DMX 2Ch’ 2-channel DMX mode

‘DMX 3Ch1’ 3-channel DMX mode 1

‘DMX 3Ch2’ 3-channel DMX mode 2

‘DMX 4Ch’ 4-channel DMX mode

‘DMX 6Ch’ 6-channel DMX mode

‘DMX 12Ch’ 12-channel DMX mode

‘DMX 14Ch’ 14-channel DMX mode

‘DMX 26Ch’ 26-channel DMX mode

‘Slave’ ‘Slave’ Operating mode ‘Slave’

‘Auto’ ‘Auto Fading’ 0…255 Automatic Fade eect

‘Auto Jumping’ 0…255 Automatic Jump eect

‘Static’ ‘Dimmer’ 0…255 Setting the overall

brightness

‘Strobe’ Strobe eect

0…5 Open strobe

6…10 Closed strobe

Operating

Co6 V2 LED Flood IP65 270W RGBW

LED oodlight
