VMB301 Condition monitoring sensor with CANopen interface
36
13 Selection of measuring axes
The status parameters are calculated from a selectable measurement axis; this measurement axis can
be a single measurement axis (e.g. Z axis) or a combination of several measurement axes (e.g. Xyz
axis).
The magnitude corresponds to the sum signal of several axes (e.g. x, y and z). Magnitude =
√(x
2
+ y
2
+z
2
)
Index Subindex
Name
(Object)
Type Access Default value Selection options
0x2050 0x00 Selection of the measuring axis for the
acceleration parameters
(a-Peak, a-RMS, Crest)
u8 rw 7 1: (x axis)
2: (y axis)
3: (xy axis)
4: (z axis)
5: (xz axis)
6: (yz axis)
7: (xyz axis)
0x2051 0x00 Selection of the measurement axis for
the speed parameters
(v-RMS)
u8 rw 7 1: (x axis)
2: (y axis)
3: (xy axis)
4: (z axis)
5: (xz axis)
6: (yz axis)
7: (xyz axis)
0x2052 0x00 Selection of the measurement axis for
the vibration displacement parameters
(d-Peak2Peak)
u8 rw 3 1: (x axis)
2: (y axis)
3: (z axis)
0x2053 0x00 Selection of the measuring axis for the
Measurement analysis
(Unbalance analysis, BearingScout™)
u8 rw 3 1: (x axis)
2: (y axis)
3: (z axis)
