Condition monitoring sensor with CANopen interface VMB301
15
TPDO
Settings for PDO
mapping
Object directo-
ry:
Mapped
object index
Object direc-
tory:
Mapped
object sub-in-
dex
Object directo-
ry:
Mapped
object length
State
Characteristics
Unit
1 Node ID + 0x180 0x7130 0x02 0x10 Process value
Fatigue (v-RMS)
m/s
0x6150 0x02 0x08 Fatigue status
(v-RMS)
-
0x7130 0x03 0x10 Process value: im-
pact
(a-Peak)
m/s²
0x6150 0x03 0x08 Status: impact
(a-Peak)
-
2 Node ID + 0x280 0x7130 0x04 0x10 Process value
Friction
(a-RMS)
m/s²
0x6150 0x04 0x08 Status: friction
(a-RMS)
-
0x7130 0x05 0x10 Process value
(Crest)
[-]
0x6150 0x05 0x08 Status (Crest) -
3 Node ID + 0x380 0x7130 0x01 0x10 Process value
Displacement
(d-Peak2Peak)
m
0x6150 0x01 0x08 Shift/offset status
(d-Peak2Peak)
-
0x7130 0x06 0x10 Surface temperature
process value
[°C]
0x6150 0x06 0x08 Surface temperature
status
-
4 Node ID + 0x480 0x7130 0x08 0x10 Process value
BearingScout™
m/s²
0x6150 0x08 0x08 Status
BearingScout™
-
5 Factory state:
deactivated
Data transfer per process data object is only possible in the "Operational" operating status.
The individual TPDO contents are shown below:
TPDO1
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8
Fatigue (v-RMS)
in [m/s]
Status: fatigue Impact (a-Peak)
in [m/s²]
Status: impact - -
OD index: 0x7130
Subindex: 0x02
OD index: 0x6150
Subindex: 0x02
OD index: 0x7130
Subindex: 0x03
OD index:
0x6150
Subindex: 0x03
- -
