Operating
mode
Output signals
2 wires OUT: - Analogue signal for temperature measurement
and diagnostics
3 wires OUT1: - Switching signal for diagnostics
or
- IO-Link signal for temperature measurement and
diagnostics
OUT2: - Analogue signal for temperature measurement
and diagnostics
5.1 IO-Link
This unit has an IO-Link communication interface which enables direct access to
process and diagnostic data� In addition it is possible to set the parameters of the
unit while it is in operation� Operation of the unit via an IO-Link interface requires
an IO-Link master�
With a PC, suitable IO-Link software and an IO-Link adapter cable communication
is possible when the system is not in operation�
The IODDs necessary for the configuration of the unit, detailed information about
process data structure, diagnostic information, parameter addresses and the
necessary information about the required IO-Link hardware and software can be
found at www�ifm�com�
5.2 Analogue function
The unit converts the measured temperature value into a temperature-proportional
analogue signal�
In addition the analogue output is used for diagnostics (→ 5.3 Diagnostic
function): The transfer of the measured temperature value is interrupted for
diagnostic messages depending on the operating mode and the setting of drEd
and an analogue signal according to NE43 of 3�5 mA (FOU2 = OFF) or 21�5 mA
(FOU2 = On) is provided�
Depending on the parameter setting (→ 8.1) the analogue signal is within the
measuring range�
