21
UK
11 Fault correction
In case of faults or anomalies:
► Connect the unit to a PC and read [Fnr] via the IO-Link interface�
► Read [Fnr]�
Fnr Type of fault Corrective measures
0 No fault, no anomaly occurred� -/-
20 Internal malfunction in the sensor
electronics�
► Replace the unit�
21 Backup function of the sensor activated,
e�g� a sensor element has failed
(diagnostic case 4 → 5.3.3)
► Replace the unit�
► Continue measurement with only one
sensor element (backup function):
- In 2-wire operation set [drEd] = ON so
that the measured temperature value
can be continued to be transferred�
Then the analogue output only
provides diagnostic cases of the
category "failure"�
- In 3-wire operation all diagnostic
cases can be signalled via the
diagnostic switching output except
those used for drift monitoring
(diagnostic cases 1, 3, 7 → 5.3.3)�
30 Wiring fault ► Check wiring�
42 Analogue signal 21�5 mA (FOU2 = On)
or 3�5 mA (FOU2 = OFF)
> The switch point is clearly outside
the measuring range�
► Check measuring range�
► Adapt [ASP] value and [AEP] vaule to
the operating conditions�
71 Detected sensor drift exceeds warning
level [drW]
First indication of drift detected�
► Check whether the parameter [drW]
is programmed correctly�
► Prepare replacement of the unit�
72 Detected sensor drift exceeds alarm
level [drA]
Drift exceeds alarm threshold�
Temperature measurement with reduced
accuracy possible�
► Check whether the parameter [drA] is
programmed correctly�
► Replace the unit�
