Ultrasonic flow meter SUH1xx SUH22x SUH3xx SUH42x SUH5xx SUH6xx SUH7xx SUH8xx
35
11 Troubleshooting
The device has many self-diagnostic options. It monitors itself automatically during operation.
Warning and error messages are output as an event via the IO-Link interface.
The status signals are classified according to NAMUR recommendation NE107.
If the measured temperature value fails, the process value for flow rate is still available.
Additional diagnostic functions are available via IO-Link Ò IO-Link interface description at
documentation.ifm.com.
11.1 Warning messages
IO-Link event
Name / code
Problem Corrective measures
Short circuit
0x7710
30480d
Short circuit on output OUT1 and / or
OUT2.
u Check output for short circuit or
excessive current.
Temperature exceeded
0x4210
16912d
Admissible internal device temperature ex-
ceeded.
u Eliminate heat sources.
Temperature not reached
0x4220
16928d
Admissible internal device temperature not
reached.
u Insulate device.
Component malfunction
0x5010
20496d
A process value is erroneous.
u Repair or replace the device.
Process value below
the valid range
0x8C30
35888d
Below the display range (UL).
Process value uncertain.
u Check measuring range.
Process value above
the valid range
0x8C10
35856d
Above the display range (OL).
Process value uncertain.
u Check measuring range.
Override active. Device status = 2
0x8CDC
36060d
A process value differs from the measured
value. PV is set to “0” while override bit is
set in PDOut.
u Deactivate PDOut override.
Signal quality low
0x8CBF
36031d
Signal quality low.
u Remove the device and check for
deposits.
u Check application for interference (air
bubbles/particles).
Simulation active
0x8C01
35841d
Simulation active.
u End simulation.
In the event of a warning, the outputs react according to the setting under [FOU] = OU.
Exception: Short circuit.
11.2 Error messages
IO-Link event
Name / code
Problem Corrective measures
Hardware fault in the device
0x5000
20480d
Device faulty / malfunction.
u Replace the device.
